2023 Toyota Sequoia Wheels & Rims: Bolt Pattern, Offset & Sizes
Fitting Toyota Sequoia wheels? This page gives the 2023 Toyota Sequoia bolt pattern (6x139.7), centre bore, factory rim size and the offset range for aftermarket and forged Toyota Sequoia rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.
Forged wheels for Toyota Sequoia — styles, sizes & factory quote →
Toyota Sequoia (2023): 6x139.7 bolt pattern, 95.1mm center bore. Factory wheels: F/R: 20x8.5J at ET60 offset, front and rear. Reference fitment ranges.
✓ Data check: the bolt pattern and center bore on this page match an independent fitment reference. Last reviewed September 18, 2026. How we verify
Wheel Size & Offset at a Glance
| Configuration | Wheel Size & Offset |
|---|---|
| Factory (OE) | F/R: 20x8.5J F/R |
| Flush Fitment | 20x9.5J at ET45 offset |
| Maximum Aggressive | 22x10.0J at ET40 offset |
Forged Wheel Designs for the Toyota Sequoia
Every design below is forged to order, so it can be machined to the Toyota Sequoia's 6x139.7 bolt pattern and 95.1 mm center bore, with the width and offset calculated for your setup.


DT Forge Pink & Chrome Multi-Spoke Wheels
H-Type · Pink / Chrome

American Force Polished Multi-Spoke Wheels
H-Type · Polished

KG1 Forged Radar Polished Forged Wheels
H-Type · Polished

MMX Design Polished 5-Spoke Forged Wheels
H-Type · Polished
How to Read Wheel Offset & Measurements
Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.


ANKUSI Engineering Expert Advice
Because an SUV's center of gravity is already higher than a sedan's, anything added at the corners — including wheel weight — has an outsized effect on handling balance. A forged wheel lets us hit the visual stance owners want without adding the rotational mass a cast wheel of the same strength would carry.
The Toyota Sequoia runs a 6x139.7 bolt pattern, 95.1mm center bore, and a 20x8.5J, front and rear, wheel from the factory. Our Flush Fitment reference is 20x9.5J ET45, which tucks the tire under the fender lip on a stock-height Toyota Sequoia. Our Maximum Aggressive reference is 22x10.0J ET40 — beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.
Toyota Sequoia OE Wheel Specs
The 2023 Toyota Sequoia (Full-Size SUV) uses a 6x139.7 bolt pattern with a 95.1mm center bore. Factory wheels are F/R: 20x8.5J F/R.
Why the factory spec works for most owners:
- Supports the vehicle's curb weight and load capacity
- Preserves ground clearance for everyday and light off-road use
- Balances ride comfort with cargo and passenger stability
- Maintains clearance for the factory suspension travel and brake package
ANKUSI builds these wheels — we are the forging factory, not a reseller. For the Toyota Sequoia (2023) we drill the 6x139.7 pattern and cut the centre bore to 95.1mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.
Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.
The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.
Offset & Backspacing Reference
Backspacing is calculated as wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance):
- OE: F/R: 20x8.5J ET60 → ~7.11″ backspacing
- Flush: 20x9.5J ET45 → ~7.02″ backspacing
- Max: 22x10.0J ET40 → ~7.07″ backspacing
A Note on Clearance
Final clearance depends on the exact tire model, suspension height, brake package, alignment and vehicle tolerances. A physical test fit is recommended before production.
Want to check a different width or offset before you order? Use our Offset & Backspacing Calculator to solve the numbers yourself, or looking for your exact Toyota spec, or want a wheel built to a custom offset for your Toyota Sequoia? Contact ANKUSI with your bolt pattern and offset target and we will confirm the correct forged wheel spec for your build.
