2024 Toyota Sequoia TRD Pro Wheels & Rims: Bolt Pattern, Offset & Sizes
Fitting Toyota Sequoia TRD Pro wheels? This page gives the 2024 Toyota Sequoia TRD Pro bolt pattern (6x139.7), centre bore, factory rim size and the offset range for aftermarket and forged Toyota Sequoia TRD Pro rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.
Toyota Sequoia TRD Pro (2024): 6x139.7 bolt pattern, 95.1mm center bore. Factory wheels: F/R: 18x8.0J at ET60 offset, front and rear. Reference fitment ranges.
✓ Data check: the bolt pattern and center bore on this page match an independent fitment reference. Last reviewed September 18, 2026. How we verify
Wheel Size & Offset at a Glance
| Configuration | Wheel Size & Offset |
|---|---|
| Factory (OE) | F/R: 18x8.0J F/R |
| Flush Fitment | 18x9.0J at ET35 offset |
| Maximum Aggressive | 20x9.5J at ET30 offset |
Forged Wheel Designs for the Toyota Sequoia TRD Pro
Every design below is forged to order, so it can be machined to the Toyota Sequoia TRD Pro's 6x139.7 bolt pattern and 95.1 mm center bore, with the width and offset calculated for your setup.


KG1 Forged Radar Polished Forged Wheels
H-Type · Polished

American Force Polished Multi-Spoke Wheels
H-Type · Polished

DT Forge Pink & Chrome Multi-Spoke Wheels
H-Type · Pink / Chrome

MMX Design Polished 5-Spoke Forged Wheels
H-Type · Polished
How to Read Wheel Offset & Measurements
Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.


ANKUSI Engineering Expert Advice
SUVs carry more curb weight higher off the ground, so wheel strength and rotational mass both matter more than on a comparable sedan — a heavier wheel amplifies body roll and slows steering response exactly where the platform is already working hardest. Forging keeps the wheel light without giving up the load rating the factory suspension geometry was tuned around.
The Toyota Sequoia TRD Pro runs a 6x139.7 bolt pattern, 95.1mm center bore, and a 18x8.0J, front and rear, wheel from the factory. Our Flush Fitment reference is 18x9.0J ET35, which tucks the tire under the fender lip on a stock-height Toyota Sequoia TRD Pro. Our Maximum Aggressive reference is 20x9.5J ET30 — beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.
Toyota Sequoia TRD Pro OE Wheel Specs
The 2024 Toyota Sequoia TRD Pro (Full-Size SUV) uses a 6x139.7 bolt pattern with a 95.1mm center bore. Factory wheels are F/R: 18x8.0J F/R.
Why the factory spec works for most owners:
- Supports the vehicle's curb weight and load capacity
- Preserves ground clearance for everyday and light off-road use
- Balances ride comfort with cargo and passenger stability
- Maintains clearance for the factory suspension travel and brake package
ANKUSI builds these wheels — we are the forging factory, not a reseller. For the Toyota Sequoia TRD Pro (2024) we drill the 6x139.7 pattern and cut the centre bore to 95.1mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.
Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.
The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.
Offset & Backspacing Reference
Backspacing is calculated as wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance):
- OE: F/R: 18x8.0J ET60 → ~6.86″ backspacing
- Flush: 18x9.0J ET35 → ~6.38″ backspacing
- Max: 20x9.5J ET30 → ~6.43″ backspacing
A Note on Clearance
Final clearance depends on the exact tire model, suspension height, brake package, alignment and vehicle tolerances. A physical test fit is recommended before production.
Want to check a different width or offset before you order? Use our Offset & Backspacing Calculator to solve the numbers yourself, or looking for your exact Toyota spec, or want a wheel built to a custom offset for your Toyota Sequoia TRD Pro? Contact ANKUSI with your bolt pattern and offset target and we will confirm the correct forged wheel spec for your build.
