2025 Jeep Wagoneer Overland Special Edition Wheels & Rims: Bolt Pattern, Offset & Sizes
Fitting Jeep Wagoneer Overland Special Edition wheels? This page gives the 2025 Jeep Wagoneer Overland Special Edition bolt pattern (6x139.7), centre bore, factory rim size and the offset range for aftermarket and forged Jeep Wagoneer Overland Special Edition rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.
Quick answer: The 2025 Jeep Wagoneer Overland Special Edition uses a 6x139.7 bolt pattern with a 77.8 mm centre bore. Factory wheels: 20x9J at ET19. For aftermarket wheels, 20x10J ET10 sits flush and 22x10.5J ET0 is the most aggressive fit.
Forged wheels for the 2025 Jeep Wagoneer Overland Special Edition — drilled 6x139.7 with a 77.8 mm centre bore, built to the offset you choose. From $220 per wheel, made to order in 20–25 days.
Get a quote for this car
Jeep Wagoneer Overland Special Edition (2025): 6x139.7 bolt pattern, 77.8mm center bore. Factory wheels: 20x9J. Reference fitment ranges.
Bolt Pattern6x139.7
Wheel Bolt/Nut1/2\"x20 Nut
Center Bore77.8mm
Wheel Load Rating900–1250 kg/wheel (SUV segment reference)
Year2025
CategorySUV
✓ Data check: the bolt pattern and center bore on this page match an independent fitment reference. Last reviewed September 18, 2026. How we verify
Wheel Size & Offset at a Glance
| Configuration | Wheel Size & Offset |
|---|---|
| Factory (OE) | 20x9J at ET19 |
| Flush Fitment | 20x10J at ET10 offset |
| Maximum Aggressive | 22x10.5J at ET0 offset |
Forged Wheel Designs for the Jeep Wagoneer Overland Special Edition
Every design below is forged to order, so it can be machined to the Jeep Wagoneer Overland Special Edition's 6x139.7 bolt pattern and 77.8 mm center bore, with the width and offset calculated for your setup.
KMC Black / Machined Riveted Off-Road Forged Wheels
Off-Road · Black Machined
Rays-Style Gloss Black 5-Spoke Off-Road Forged Wheels
Off-Road · Gloss Black
Shelby-Style Gunmetal / Black Split-Spoke Beadlock Off-Road Forged Wheels
Off-Road Beadlock · Gunmetal / Black
D&L-Style Polished Mesh Black Bolted Ring Beadlock Off-Road Forged Wheels
Off-Road Beadlock · Polished
Matte White 20-Spoke Exposed Bolt Detail Forged Wheels
Off-Road · Matte White
Gloss Black Orange-Ring Beadlock Forged Wheels
Off-Road Beadlock · Gloss Black Orange
Black Rhino-Style Satin Black 5-Spoke Off-Road Forged Wheels
Off-Road · Satin Black
How to Read Wheel Offset & Measurements
Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.
ANKUSI Engineering Expert Advice
Because an SUV's center of gravity is already higher than a sedan's, anything added at the corners — including wheel weight — has an outsized effect on handling balance. A forged wheel lets us hit the visual stance owners want without adding the rotational mass a cast wheel of the same strength would carry.
The Jeep Wagoneer Overland Special Edition runs a 6x139.7 bolt pattern, 77.8mm center bore, and a 20x9J at ET19, front and rear, wheel from the factory. Our Flush Fitment reference is 20x10J ET10, which tucks the tire under the fender lip on a stock-height Jeep Wagoneer Overland Special Edition. Our Maximum Aggressive reference is 22x10.5J ET0 — beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.
Jeep Wagoneer Overland Special Edition OE Wheel Specs
The 2025 Jeep Wagoneer Overland Special Edition (SUV) uses a 6x139.7 bolt pattern with a 77.8mm center bore. Factory wheels are 20x9J at ET19.
Why the factory spec works for most owners:
- Supports the vehicle's curb weight and load capacity
- Preserves ground clearance for everyday and light off-road use
- Balances ride comfort with cargo and passenger stability
- Maintains clearance for the factory suspension travel and brake package
ANKUSI builds these wheels — we are the forging factory, not a reseller. For the Jeep Wagoneer Overland Special Edition (2025) we drill the 6x139.7 pattern and cut the centre bore to 77.8mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.
Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.
The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.
Real-World Fitment Notes
Chassis: Air suspension lift. Tires: 285/50 R20 all-terrain.
Offset & Backspacing Reference
Backspacing is calculated as wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance):
- OE: 20x9J ET19 → ~5.75″ backspacing
- Flush: 20x10J ET10 → ~5.89″ backspacing
- Max: 22x10.5J ET0 → ~5.75″ backspacing
A Note on Clearance
Final clearance depends on the exact tire model, suspension height, brake package, alignment and vehicle tolerances. A physical test fit is recommended before production.
Want to check a different width or offset before you order? Use our Offset & Backspacing Calculator to solve the numbers yourself, or looking for your exact Jeep spec, or want a wheel built to a custom offset for your Jeep Wagoneer Overland Special Edition? Contact ANKUSI with your bolt pattern and offset target and we will confirm the correct forged wheel spec for your build.
Vehicles With the Same Hub as the Jeep Wagoneer Overland Special Edition (6x139.7, 77.8 mm Bore)
In our database, 31 other vehicle entries from 5 makes use exactly the same 6x139.7 bolt pattern and 77.8 mm center bore. Factory wheels from these cars bolt on and center on the hub without rings; offset and width still have to be checked.
6x139.7 is used by 4.0% of the vehicle pages in our English fitment guide (258 of 6,503); 12.4% of those also use a 77.8 mm center bore.
Hub-Centric Rings for a 77.8 mm Center Bore
A wheel with a center bore larger than 77.8 mm needs a hub-centric ring. The most common combinations:
| Wheel bore | Ring size |
|---|---|
| 78.1 mm | 78.1 → 77.8 mm |
| 84.1 mm | 84.1 → 77.8 mm |
| 93.1 mm | 93.1 → 77.8 mm |
| 100.1 mm | 100.1 → 77.8 mm |
ANKUSI forged wheels are bored to exactly 77.8 mm for this vehicle, so no ring is needed.
Frequently Asked Questions
What bolt pattern (PCD) does the Jeep Wagoneer Overland Special Edition use?
The 2025 Jeep Wagoneer Overland Special Edition uses a 6x139.7 bolt pattern.
How many lug bolts does the Jeep Wagoneer Overland Special Edition use?
The Jeep Wagoneer Overland Special Edition uses a 6-lug bolt pattern (6x139.7), so you need a 6-lug forged wheel to bolt straight on.
What is the center bore size on the Jeep Wagoneer Overland Special Edition?
The Jeep Wagoneer Overland Special Edition's center bore is 77.8mm. If an aftermarket wheel has a larger center bore than this, hub-centric rings are recommended so the wheel centers on the hub itself rather than relying on the lug bolts alone.
What size are the factory (stock) wheels on the Jeep Wagoneer Overland Special Edition?
Factory wheels on the Jeep Wagoneer Overland Special Edition are 20x9J at ET19.
What is the biggest wheel size I can fit on my Jeep Wagoneer Overland Special Edition without rubbing?
The most aggressive fitment we recommend without fender work is 22x10.5J at ET0 offset. Going beyond this typically causes rubbing under compression unless you roll the fenders or add camber correction.
What does a flush wheel fitment look like on the Jeep Wagoneer Overland Special Edition?
For a flush look with minimal to no rubbing, we recommend 20x10J at ET10 offset as a starting point on a stock or mildly lowered Jeep Wagoneer Overland Special Edition.
Do I need wheel spacers for my Jeep Wagoneer Overland Special Edition?
No. ANKUSI forges each wheel to your exact target offset, including the flush or max specs above, so you get the correct fitment without stacking spacers. Spacers are typically only used to push out an existing OE-offset wheel without replacing it, which isn't necessary when you're ordering a custom-offset forged wheel.
How do I calculate wheel backspacing for my Jeep Wagoneer Overland Special Edition?
Backspacing (in inches) = wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance). For example, the flush spec above works out to roughly 5.89" of backspacing.
What's the difference between wheel offset and backspacing?
Offset is the distance in millimeters from the wheel's true centerline to its mounting face (positive offset pulls the wheel in, negative pushes it out). Backspacing is the distance in inches from the mounting face to the back edge of the wheel barrel. They describe the same fitment from two different reference points, which is why ANKUSI lists both above — some shops and tuning guides quote offset, others quote backspacing.
Can I run staggered wheels (different sizes front and rear) on my Jeep Wagoneer Overland Special Edition?
The Jeep Wagoneer Overland Special Edition runs the same wheel size front and rear from the factory, so staggered fitment is not required. ANKUSI can still forge a staggered set (wider rear) on request if you want a more aggressive stance.
Sources and Last Update
Data checked against: avtoreference.com.
This record is part of the open ANKUSI Wheel Fitment Dataset (DOI 10.5281/zenodo.23241521, CC BY 4.0).
Other cars on the same factory size: 20x9 wheels · 20 inch wheels.
Compiled by the ANKUSI Wheels engineering team, an IATF 16949 and ISO 9001 certified forged wheel factory in Guangzhou.
