2007 Toyota FJ Cruiser Wheels & Rims: Bolt Pattern, Offset & Sizes
Fitting Toyota FJ Cruiser wheels? This page gives the 2007 Toyota FJ Cruiser bolt pattern (6x139.7), centre bore, factory rim size and the offset range for aftermarket and forged Toyota FJ Cruiser rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.
Toyota FJ Cruiser (2007): 6x139.7 bolt pattern, 106.1mm center bore. Factory wheels: F/R: 17x7.5J at ET15 offset, front and rear. Reference fitment ranges.
✓ Data check: the bolt pattern and center bore on this page match an independent fitment reference. Last reviewed September 18, 2026. How we verify
Wheel Size & Offset at a Glance
| Configuration | Wheel Size & Offset |
|---|---|
| Factory (OE) | F/R: 17x7.5J F/R |
| Flush Fitment | 17x8.5J at ET0 offset |
| Maximum Aggressive | 18x9.0J at ET-5 offset |
Forged Wheel Designs for the Toyota FJ Cruiser
Every design below is forged to order, so it can be machined to the Toyota FJ Cruiser's 6x139.7 bolt pattern and 106.1 mm center bore, with the width and offset calculated for your setup.


KG1 Forged Radar Polished Forged Wheels
H-Type · Polished

DT Forge Pink & Chrome Multi-Spoke Wheels
H-Type · Pink / Chrome

American Force Polished Multi-Spoke Wheels
H-Type · Polished

MMX Design Polished 5-Spoke Forged Wheels
H-Type · Polished
How to Read Wheel Offset & Measurements
Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.


ANKUSI Engineering Expert Advice
The Toyota FJ Cruiser's factory suspension tuning already accounts for a specific unsprung mass target. Forged construction lets ANKUSI match the factory strength spec while keeping rotational weight down, which is where the real handling benefit comes from on a taller, heavier SUV platform.
The Toyota FJ Cruiser runs a 6x139.7 bolt pattern, 106.1mm center bore, and a 17x7.5J, front and rear, wheel from the factory. Our Flush Fitment reference is 17x8.5J ET0, which tucks the tire under the fender lip on a stock-height Toyota FJ Cruiser. Our Maximum Aggressive reference is 18x9.0J ET-5 — beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.
Toyota FJ Cruiser OE Wheel Specs
The 2007 Toyota FJ Cruiser (Off-Road SUV) uses a 6x139.7 bolt pattern with a 106.1mm center bore. Factory wheels are F/R: 17x7.5J F/R.
Why the factory spec works for most owners:
- Supports the vehicle's curb weight and load capacity
- Preserves ground clearance for everyday and light off-road use
- Balances ride comfort with cargo and passenger stability
- Maintains clearance for the factory suspension travel and brake package
ANKUSI builds these wheels — we are the forging factory, not a reseller. For the Toyota FJ Cruiser (2007) we drill the 6x139.7 pattern and cut the centre bore to 106.1mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.
Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.
The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.
Offset & Backspacing Reference
Backspacing is calculated as wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance):
- OE: F/R: 17x7.5J ET15 → ~4.84″ backspacing
- Flush: 17x8.5J ET0 → ~4.75″ backspacing
- Max: 18x9.0J ET-5 → ~4.8″ backspacing
A Note on Clearance
Final clearance depends on the exact tire model, suspension height, brake package, alignment and vehicle tolerances. A physical test fit is recommended before production.
Want to check a different width or offset before you order? Use our Offset & Backspacing Calculator to solve the numbers yourself, or looking for your exact Toyota spec, or want a wheel built to a custom offset for your Toyota FJ Cruiser? Contact ANKUSI with your bolt pattern and offset target and we will confirm the correct forged wheel spec for your build.
Frequently Asked Questions
What bolt pattern (PCD) does the Toyota FJ Cruiser use?
How many lug bolts does the Toyota FJ Cruiser use?
What is the center bore size on the Toyota FJ Cruiser?
What size are the factory (stock) wheels on the Toyota FJ Cruiser?
What is the biggest wheel size I can fit on my Toyota FJ Cruiser without rubbing?
What does a flush wheel fitment look like on the Toyota FJ Cruiser?
Do I need wheel spacers for my Toyota FJ Cruiser?
How do I calculate wheel backspacing for my Toyota FJ Cruiser?
What's the difference between wheel offset and backspacing?
Can I run staggered wheels (different sizes front and rear) on my Toyota FJ Cruiser?
Wheel Installation Reference: Torque, Thread & TPMS
Thread & Fastener: M12x1.5, conical-seat lug nut.
Factory Torque Spec: 103-110 Nm (76-81 ft-lb). Range covers most Toyota passenger cars, crossovers, and light trucks on M12x1.5 studs.
TPMS: Vehicles built before the 2008 model year were not federally required to carry factory TPMS in the US, though many manufacturers adopted it earlier; verify whether your specific build has TPMS before ordering sensor-compatible wheels.
Tire Pressure: Always set tire pressure to the value on your vehicle's tire placard (driver's doorjamb or glovebox), not the max PSI printed on the tire sidewall — this is trim- and tire-size-specific and stays the same reference point when you switch to a different wheel and tire combination.
Reference data compiled from published OEM service specifications and cross-checked against independent repair sources; always confirm against your owner's manual or door-jamb placard before installation.
