Toyota Tacoma Wheels & Rims, Forged to Order
Forged Toyota Tacoma wheels and rims are listed here, in 14 to 24 inch diameters. Each one is forged to order from 6061-T6 aluminium and machined to your generation's bolt pattern and centre bore, with width and offset calculated for the stance you want: factory-flush, flush or aggressive.
Reference price from $240 per wheel; final quote depends on size, finish and quantity.
Toyota Tacoma setups and prices
Toyota Tacoma wheel specs by generation
| Model / year | Bolt pattern | Center bore | Factory wheels |
|---|---|---|---|
| Toyota Tacoma (2024) | 6x139.7 | 95.1 mm | F/R 17x7.5J |
| Toyota Tacoma TRD Pro (2024) | 6x139.7 | 95.1 mm | F/R: 18x7.5J at ET35 offset, front and rear |
| Toyota Tacoma TRD Pro (2022) | 6x139.7 | 106.1 mm | F/R: 16x7.0J at ET30 offset, front and rear |
| Toyota Tacoma (2020) | 6x139.7 | 106.1 mm | F/R: 16x7.0J at ET30 offset, front and rear |
| Toyota Tacoma TRD Pro (2019) | 6x139.7 | 106.1 mm | F/R: 16x7.0J at ET30 offset, front and rear |
| Toyota Tacoma TRD Pro (2017) | 6x139.7 | 106.1 mm | F/R: 16x7.0J at ET30 offset, front and rear |
| Toyota Tacoma (2016) | 6x139.7 | 106.1 mm | F/R: 16x7.0J at ET30 offset, front and rear |
| Toyota Tacoma TRD Pro Series (2015) | 6x139.7 | 106.1 mm | F/R: 16x7.0J at ET30 offset, and rear |
| Toyota Tacoma (2012) | 6x139.7 | 106.1 mm | F/R: 16x7.0J at ET30 offset, front and rear |
| Toyota Tacoma (2011) | 6x139.7 | 106.1 mm | F/R: 16x7.0J at ET30 offset, front and rear |
Data from our fitment database. Open a row for flush and maximum sizes, offsets and FAQs.
Toyota wheel fitment guide: bolt pattern, center bore and offset for every model →
All 1 designs
Browse more collections
Toyota GR86 Wheels & Rims, Forged to OrderToyota Forged WheelsToyota 4Runner Wheels & Rims, Forged to OrderToyota Land Cruiser Wheels & Rims, Forged to OrderToyota GR Supra Wheels & Rims, Forged to OrderToyota Supra Wheels & Rims, Forged to OrderToyota Camry Wheels & Rims, Forged to OrderToyota Crown Wheels & Rims, Forged to OrderToyota Corolla Wheels & Rims, Forged to OrderTesla Model Y Wheels & Rims, Forged to OrderTesla Model 3 Wheels & Rims, Forged to OrderAudi RS3 Wheels & Rims, Forged to OrderBMW M4 Wheels & Rims, Forged to OrderVolkswagen Tiguan Wheels & Rims, Forged to OrderBronze Forged WheelsGloss Black Forged WheelsY-Spoke Forged WheelsDeep Lip Forged WheelsConcave Forged Wheels2-Piece Forged Wheels
Vehicles With the Same Hub as the Toyota Tacoma (6x139.7, 106.1 mm Bore)
In our database, 10 other vehicle entries from 6 makes use exactly the same 6x139.7 bolt pattern and 106.1 mm center bore. Factory wheels from these cars bolt on and center on the hub without rings; offset and width still have to be checked.
6x139.7 is used by 4.0% of the vehicle pages in our English fitment guide (258 of 6,503); 12.8% of those also use a 106.1 mm center bore.
Hub-Centric Rings for a 106.1 mm Center Bore
A wheel with a center bore larger than 106.1 mm needs a hub-centric ring. The most common combinations:
| Wheel bore | Ring size |
|---|---|
| 108.1 mm | 108.1 → 106.1 mm |
| 110.1 mm | 110.1 → 106.1 mm |
| 130.1 mm | 130.1 → 106.1 mm |
ANKUSI forged wheels are bored to exactly 106.1 mm for this vehicle, so no ring is needed.
Sources and Last Update
Bolt pattern and center bore were checked against at least two independent fitment references before publication.
This record is part of the open ANKUSI Wheel Fitment Dataset (DOI 10.5281/zenodo.23241521, CC BY 4.0).
Compiled by the ANKUSI Wheels engineering team, an IATF 16949 and ISO 9001 certified forged wheel factory in Guangzhou.
Custom Inquiry
Don't see the exact design or finish?
Send your vehicle, target size, offset and finish, or a photo of the wheel you like. We confirm fitment and factory-direct pricing.
