2023 Toyota Corolla Cross (EU) Wheels & Rims: Bolt Pattern, Offset & Sizes
Fitting Toyota Corolla Cross (EU) wheels? This page gives the 2023 Toyota Corolla Cross (EU) bolt pattern (5x114.3), centre bore, factory rim size and the offset range for aftermarket and forged Toyota Corolla Cross (EU) rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.
Toyota Corolla Cross (EU) (2023): 5x114.3 bolt pattern, 60.1mm center bore. Factory wheels: F/R: 17x6.5J at ET40 offset, front and rear. Reference fitment ranges.
Bolt Pattern5x114.3
Wheel Bolt/NutM12x1.5 Nut
Center Bore60.1mm
Wheel Load Rating800–950 kg/wheel (Crossover segment reference)
Year2023
CategoryCrossover
✓ Data check: the bolt pattern and center bore on this page match an independent fitment reference. Last reviewed September 18, 2026. How we verify
Wheel Size & Offset at a Glance
| Configuration | Wheel Size & Offset |
|---|---|
| Factory (OE) | F/R: 17x6.5J F/R |
| Flush Fitment | 18x7.5J at ET38 offset |
| Maximum Aggressive | 19x8.0J at ET35 offset |
Forged Wheel Designs for the Toyota Corolla Cross (EU)
Every design below is forged to order, so it can be machined to the Toyota Corolla Cross (EU)'s 5x114.3 bolt pattern and 60.1 mm center bore, with the width and offset calculated for your setup.
APEX-Style Chrome 5 Y-Spoke Forged Wheels
Monoblock · Chrome
Toyota OEM-Style Brushed Silver Mesh Multi-Spoke Forged Wheels
Monoblock · Brushed Silver
Toyota OEM-Style Mirror Polished Full-Face Forged Wheels
Monoblock · Mirror Polished
Rays Volk Racing TE37-Style Bronze Forged Wheels
Replica · Bronze
Advan Racing Gloss White 6-Spoke Forged Wheels
Replica · Gloss White
BBS RE-V7-Style Titanium Gold 7 Y-Spoke Forged Wheels
Replica · Titanium Gold
Rays-Style Metallic Gray 5 Y-Spoke Forged Wheels
Replica · Metallic Gray
How to Read Wheel Offset & Measurements
Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.
ANKUSI Engineering Expert Advice
The Toyota Corolla Cross (EU)'s factory suspension tuning already accounts for a specific unsprung mass target. Forged construction lets ANKUSI match the factory strength spec while keeping rotational weight down, which is where the real handling benefit comes from on a taller, heavier SUV platform.
The Toyota Corolla Cross (EU) runs a 5x114.3 bolt pattern, 60.1mm center bore, and a 17x6.5J, front and rear, wheel from the factory. Our Flush Fitment reference is 18x7.5J ET38, which tucks the tire under the fender lip on a stock-height Toyota Corolla Cross (EU). Our Maximum Aggressive reference is 19x8.0J ET35 — beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.
Toyota Corolla Cross (EU) OE Wheel Specs
The 2023 Toyota Corolla Cross (EU) (Crossover) uses a 5x114.3 bolt pattern with a 60.1mm center bore. Factory wheels are F/R: 17x6.5J F/R.
Why the factory spec works for most owners:
- Supports the vehicle's curb weight and load capacity
- Preserves ground clearance for everyday and light off-road use
- Balances ride comfort with cargo and passenger stability
- Maintains clearance for the factory suspension travel and brake package
ANKUSI builds these wheels — we are the forging factory, not a reseller. For the Toyota Corolla Cross (EU) (2023) we drill the 5x114.3 pattern and cut the centre bore to 60.1mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.
Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.
The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.
Offset & Backspacing Reference
Backspacing is calculated as wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance):
- OE: F/R: 17x6.5J ET40 → ~5.32″ backspacing
- Flush: 18x7.5J ET38 → ~5.75″ backspacing
- Max: 19x8.0J ET35 → ~5.88″ backspacing
A Note on Clearance
Final clearance depends on the exact tire model, suspension height, brake package, alignment and vehicle tolerances. A physical test fit is recommended before production.
Want to check a different width or offset before you order? Use our Offset & Backspacing Calculator to solve the numbers yourself, or looking for your exact Toyota spec, or want a wheel built to a custom offset for your Toyota Corolla Cross (EU)? Contact ANKUSI with your bolt pattern and offset target and we will confirm the correct forged wheel spec for your build.
Frequently Asked Questions
What bolt pattern (PCD) does the Toyota Corolla Cross (EU) use?
The 2023 Toyota Corolla Cross (EU) uses a 5x114.3 bolt pattern.
How many lug bolts does the Toyota Corolla Cross (EU) use?
The Toyota Corolla Cross (EU) uses a 5-lug bolt pattern (5x114.3), so you need a 5-lug forged wheel to bolt straight on.
What is the center bore size on the Toyota Corolla Cross (EU)?
The Toyota Corolla Cross (EU)'s center bore is 60.1mm. If an aftermarket wheel has a larger center bore than this, hub-centric rings are recommended so the wheel centers on the hub itself rather than relying on the lug bolts alone.
What size are the factory (stock) wheels on the Toyota Corolla Cross (EU)?
Factory wheels on the Toyota Corolla Cross (EU) are F/R: 17x6.5J F/R.
What is the biggest wheel size I can fit on my Toyota Corolla Cross (EU) without rubbing?
The most aggressive fitment we recommend without fender work is 19x8.0J at ET35 offset. Going beyond this typically causes rubbing under compression unless you roll the fenders or add camber correction.
What does a flush wheel fitment look like on the Toyota Corolla Cross (EU)?
For a flush look with minimal to no rubbing, we recommend 18x7.5J at ET38 offset as a starting point on a stock or mildly lowered Toyota Corolla Cross (EU).
Do I need wheel spacers for my Toyota Corolla Cross (EU)?
No. ANKUSI forges each wheel to your exact target offset, including the flush or max specs above, so you get the correct fitment without stacking spacers. Spacers are typically only used to push out an existing OE-offset wheel without replacing it, which isn't necessary when you're ordering a custom-offset forged wheel.
How do I calculate wheel backspacing for my Toyota Corolla Cross (EU)?
Backspacing (in inches) = wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance). For example, the flush spec above works out to roughly 5.75" of backspacing.
What's the difference between wheel offset and backspacing?
Offset is the distance in millimeters from the wheel's true centerline to its mounting face (positive offset pulls the wheel in, negative pushes it out). Backspacing is the distance in inches from the mounting face to the back edge of the wheel barrel. They describe the same fitment from two different reference points, which is why ANKUSI lists both above — some shops and tuning guides quote offset, others quote backspacing.
Can I run staggered wheels (different sizes front and rear) on my Toyota Corolla Cross (EU)?
The Toyota Corolla Cross (EU) runs the same wheel size front and rear from the factory, so staggered fitment is not required. ANKUSI can still forge a staggered set (wider rear) on request if you want a more aggressive stance.
Wheel Installation Reference: Torque, Thread & TPMS
Thread & Fastener: M12x1.5, conical-seat lug nut.
Factory Torque Spec: 103-110 Nm (76-81 ft-lb). Range covers most Toyota passenger cars, crossovers, and light trucks on M12x1.5 studs.
TPMS: TPMS (Tire Pressure Monitoring System) has been federally mandated on all new light vehicles sold in the US since the 2008 model year. If your wheels use OE-style sensors, have them transferred or cloned to the new wheels at installation.
Tire Pressure: Always set tire pressure to the value on your vehicle's tire placard (driver's doorjamb or glovebox), not the max PSI printed on the tire sidewall — this is trim- and tire-size-specific and stays the same reference point when you switch to a different wheel and tire combination.
Reference data compiled from published OEM service specifications and cross-checked against independent repair sources; always confirm against your owner's manual or door-jamb placard before installation.
