Metallic Gray Split Directional Milled Forged Wheels
Monoblock · Metallic Gray
Fitting Porsche Cayman wheels? This page gives the 2009 Porsche Cayman bolt pattern (5x130), centre bore, factory rim size and the offset range for aftermarket and forged Porsche Cayman rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.
Porsche Cayman (2009): 5x130 bolt pattern, 71.6mm center bore. Factory wheels: F: 17x7J R: 17x8.5J. Reference fitment ranges.
✓ Data check: the bolt pattern and center bore on this page match an independent fitment reference. Last reviewed September 18, 2026. How we verify
| Configuration | Wheel Size & Offset |
|---|---|
| Factory (OE) | F: 17x7J R: 17x8.5J |
| Flush Fitment | F 18x8J ET57 / R 18x9J ET43 |
| Maximum Aggressive | F 18x8.5J ET45 / R 18x10J ET36 |
Every design below is forged to order, so it can be machined to the Porsche Cayman's 5x130 bolt pattern and 71.6 mm center bore, with the width and offset calculated for your setup.

Monoblock · Metallic Gray

Replica · Gold

Monoblock · Gloss Black

Monoblock · Black / White

Monoblock · Black Machined

Deep Dish · Silver

Monoblock · Silver / Gunmetal

Monoblock · Matte Navy Blue
Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.


On a performance-oriented coupe, the wheel is one of the few components where shaving weight has a compounding effect - less rotational mass means less work for the brakes, the drivetrain, and the chassis on every input. A forged wheel gets there without compromising the strength margin the factory engineered in.
The Porsche Cayman runs a 5x130 fitment, 71.6mm center bore, and a F: 17x7J wheel from the factory. Our Flush Fitment reference is F 18x8J ET57 / R 18x9J ET43, which tucks the tire under the fender lip on a stock-height Porsche Cayman. Our Maximum Aggressive reference is F 18x8.5J ET45 / R 18x10J ET36 - beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.
The 2009 Porsche Cayman (Sports Coupe) uses a 5x130 bolt pattern with a 71.6mm center bore. Factory wheels are F: 17x7J R: 17x8.5J.
Why the factory spec works for most owners:
ANKUSI builds these wheels — we are the forging factory, not a reseller. For the Porsche Cayman (2009) we drill the 5x130 pattern and cut the centre bore to 71.6mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.
Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.
The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.
18x9J ET46 (245/35) & 18x10J ET36 (275/35) - documented 987 build mid-engine, keep rear wider; 5x130 71.6mm; verify caliper clearance. Verified via 987 platform community data.
Backspacing is calculated as wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance):
Final clearance depends on the exact tire model, suspension height, brake package, alignment and vehicle tolerances. A physical test fit is recommended before production.
Want to check a different width or offset before you order? Use our Offset & Backspacing Calculator to solve the numbers yourself, or looking for your exact Porsche spec, or want a wheel built to a custom offset for your Porsche Cayman? Contact ANKUSI with your bolt pattern and offset target and we will confirm the correct forged wheel spec for your build.
