2003 Nissan Xterra Wheels & Rims: Bolt Pattern, Offset & Sizes
Fitting Nissan Xterra wheels? This page gives the 2003 Nissan Xterra bolt pattern (6x139.7), centre bore, factory rim size and the offset range for aftermarket and forged Nissan Xterra rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.
Nissan Xterra (2003): 6x139.7 bolt pattern, 100.1mm center bore. Factory wheels: 15x7.0J at ET40 offset, front and rear. Reference fitment ranges.
✓ Data check: the bolt pattern and center bore on this page match an independent fitment reference. Last reviewed September 18, 2026. How we verify
Wheel Size & Offset at a Glance
| Configuration | Wheel Size & Offset |
|---|---|
| Factory (OE) | 15x7.0J F/R |
| Flush Fitment | 15x8.0J at ET20 offset |
| Maximum Aggressive | 16x8.0J at ET10 offset |
Forged Wheel Designs for the Nissan Xterra
Every design below is forged to order, so it can be machined to the Nissan Xterra's 6x139.7 bolt pattern and 100.1 mm center bore, with the width and offset calculated for your setup.


KG1 Forged Radar Polished Forged Wheels
H-Type · Polished

DT Forge Pink & Chrome Multi-Spoke Wheels
H-Type · Pink / Chrome

American Force Polished Multi-Spoke Wheels
H-Type · Polished

MMX Design Polished 5-Spoke Forged Wheels
H-Type · Polished
How to Read Wheel Offset & Measurements
Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.


ANKUSI Engineering Expert Advice
Because an SUV's center of gravity is already higher than a sedan's, anything added at the corners — including wheel weight — has an outsized effect on handling balance. A forged wheel lets us hit the visual stance owners want without adding the rotational mass a cast wheel of the same strength would carry.
The Nissan Xterra runs a 6x139.7 bolt pattern, 100.1mm center bore, and a 15x7.0J, front and rear, wheel from the factory. Our Flush Fitment reference is 15x8.0J ET20, which tucks the tire under the fender lip on a stock-height Nissan Xterra. Our Maximum Aggressive reference is 16x8.0J ET10 — beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.
Nissan Xterra OE Wheel Specs
The 2003 Nissan Xterra (SUV) uses a 6x139.7 bolt pattern with a 100.1mm center bore. Factory wheels are 15x7.0J F/R.
Why the factory spec works for most owners:
- Supports the vehicle's curb weight and load capacity
- Preserves ground clearance for everyday and light off-road use
- Balances ride comfort with cargo and passenger stability
- Maintains clearance for the factory suspension travel and brake package
ANKUSI builds these wheels — we are the forging factory, not a reseller. For the Nissan Xterra (2003) we drill the 6x139.7 pattern and cut the centre bore to 100.1mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.
Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.
The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.
Offset & Backspacing Reference
Backspacing is calculated as wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance):
- OE: 15x7.0J ET40 → ~5.57″ backspacing
- Flush: 15x8.0J ET20 → ~5.29″ backspacing
- Max: 16x8.0J ET10 → ~4.89″ backspacing
A Note on Clearance
Final clearance depends on the exact tire model, suspension height, brake package, alignment and vehicle tolerances. A physical test fit is recommended before production.
Want to check a different width or offset before you order? Use our Offset & Backspacing Calculator to solve the numbers yourself, or looking for your exact Nissan spec, or want a wheel built to a custom offset for your Nissan Xterra? Contact ANKUSI with your bolt pattern and offset target and we will confirm the correct forged wheel spec for your build.
Frequently Asked Questions
What bolt pattern (PCD) does the Nissan Xterra use?
How many lug bolts does the Nissan Xterra use?
What is the center bore size on the Nissan Xterra?
What size are the factory (stock) wheels on the Nissan Xterra?
What is the biggest wheel size I can fit on my Nissan Xterra without rubbing?
What does a flush wheel fitment look like on the Nissan Xterra?
Do I need wheel spacers for my Nissan Xterra?
How do I calculate wheel backspacing for my Nissan Xterra?
What's the difference between wheel offset and backspacing?
Can I run staggered wheels (different sizes front and rear) on my Nissan Xterra?
Wheel Installation Reference: Torque, Thread & TPMS
Thread & Fastener: M12x1.25, conical-seat lug nut.
Factory Torque Spec: 103-122 Nm (76-90 ft-lb). Range covers most Nissan passenger cars and crossovers on M12x1.25 studs.
TPMS: Vehicles built before the 2008 model year were not federally required to carry factory TPMS in the US, though many manufacturers adopted it earlier; verify whether your specific build has TPMS before ordering sensor-compatible wheels.
Tire Pressure: Always set tire pressure to the value on your vehicle's tire placard (driver's doorjamb or glovebox), not the max PSI printed on the tire sidewall — this is trim- and tire-size-specific and stays the same reference point when you switch to a different wheel and tire combination.
Reference data compiled from published OEM service specifications and cross-checked against independent repair sources; always confirm against your owner's manual or door-jamb placard before installation.
