2011 Dodge Grand Caravan Wheels & Rims: Bolt Pattern, Offset & Sizes
Fitting Dodge Grand Caravan wheels? This page gives the 2011 Dodge Grand Caravan bolt pattern (5x127), centre bore, factory rim size and the offset range for aftermarket and forged Dodge Grand Caravan rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.
Forged wheels for Dodge Grand Caravan — styles, sizes & factory quote →
Dodge Grand Caravan (2011): 5x127 bolt pattern, 71.5mm center bore. Factory wheels: 16x6.5J at ET40 offset, front and rear. Reference fitment ranges.
Bolt Pattern5x127
Wheel Bolt/NutM12x1.5 Nut
Center Bore71.5mm
Wheel Load Rating900–1100 kg/wheel (Van / MPV segment reference)
Year2011
CategoryMinivan
✓ Data check: the bolt pattern and center bore on this page match an independent fitment reference. Last reviewed September 18, 2026. How we verify
Wheel Size & Offset at a Glance
| Configuration | Wheel Size & Offset |
|---|---|
| Factory (OE) | 16x6.5J F/R |
| Flush Fitment | 18x8.0J at ET40 offset |
| Maximum Aggressive | 19x8.5J at ET38 offset |
Forged Wheel Designs for the Dodge Grand Caravan
Every design below is forged to order, so it can be machined to the Dodge Grand Caravan's 5x127 bolt pattern and 71.5 mm center bore, with the width and offset calculated for your setup.
Weld Racing-Style Gloss Black Machined Twin 10-Spoke Forged Drag Racing Wheels
Drag Racing · Gloss Black / Machined
Weld Racing-Style Chrome 10-Spoke Lettered Lip Forged Drag Racing Wheels
Drag Racing · Chrome
Weld Racing-Style Gloss Black / Machined 5 Y-Spoke Forged Drag Racing Wheels
Drag Racing · Gloss Black / Machined
Matte Silver 5-Star Twin-Spoke Forged Wheels
Monoblock · Matte Silver
Weld Racing-Style Mirror Polished 12-Spoke Forged Drag Racing Wheels
Drag Racing · Mirror Polished
How to Read Wheel Offset & Measurements
Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.
ANKUSI Engineering Expert Advice
A minivan's wheel spec has to work across a wide load range — empty commute or full family trip. Forged construction preserves the factory's load-rating margin while cutting rotational weight, which keeps ride quality consistent across that range.
The Dodge Grand Caravan runs a 5x127 bolt pattern, 71.5mm center bore, and a 16x6.5J, front and rear, wheel from the factory. Our Flush Fitment reference is 18x8.0J ET40, which tucks the tire under the fender lip on a stock-height Dodge Grand Caravan. Our Maximum Aggressive reference is 19x8.5J ET38 — beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.
Dodge Grand Caravan OE Wheel Specs
The 2011 Dodge Grand Caravan (Minivan) uses a 5x127 bolt pattern with a 71.5mm center bore. Factory wheels are 16x6.5J F/R.
Why the factory spec works for most owners:
- Supports passenger and cargo load capacity
- Balances ride comfort with everyday practicality
- A widely used size for this vehicle class, supporting parts and tire availability
- Maintains clearance for the factory suspension and brake package
ANKUSI builds these wheels — we are the forging factory, not a reseller. For the Dodge Grand Caravan (2011) we drill the 5x127 pattern and cut the centre bore to 71.5mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.
Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.
The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.
Offset & Backspacing Reference
Backspacing is calculated as wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance):
- OE: 16x6.5J ET40 → ~5.32″ backspacing
- Flush: 18x8.0J ET40 → ~6.07″ backspacing
- Max: 19x8.5J ET38 → ~6.25″ backspacing
A Note on Clearance
Final clearance depends on the exact tire model, suspension height, brake package, alignment and vehicle tolerances. A physical test fit is recommended before production.
Want to check a different width or offset before you order? Use our Offset & Backspacing Calculator to solve the numbers yourself, or looking for your exact Dodge spec, or want a wheel built to a custom offset for your Dodge Grand Caravan? Contact ANKUSI with your bolt pattern and offset target and we will confirm the correct forged wheel spec for your build.
Frequently Asked Questions
What bolt pattern (PCD) does the Dodge Grand Caravan use?
The 2011 Dodge Grand Caravan uses a 5x127 bolt pattern.
How many lug bolts does the Dodge Grand Caravan use?
The Dodge Grand Caravan uses a 5-lug bolt pattern (5x127), so you need a 5-lug forged wheel to bolt straight on.
What is the center bore size on the Dodge Grand Caravan?
The Dodge Grand Caravan's center bore is 71.5mm. If an aftermarket wheel has a larger center bore than this, hub-centric rings are recommended so the wheel centers on the hub itself rather than relying on the lug bolts alone.
What size are the factory (stock) wheels on the Dodge Grand Caravan?
Factory wheels on the Dodge Grand Caravan are 16x6.5J F/R.
What is the biggest wheel size I can fit on my Dodge Grand Caravan without rubbing?
The most aggressive fitment we recommend without fender work is 19x8.5J at ET38 offset. Going beyond this typically causes rubbing under compression unless you roll the fenders or add camber correction.
What does a flush wheel fitment look like on the Dodge Grand Caravan?
For a flush look with minimal to no rubbing, we recommend 18x8.0J at ET40 offset as a starting point on a stock or mildly lowered Dodge Grand Caravan.
Do I need wheel spacers for my Dodge Grand Caravan?
No. ANKUSI forges each wheel to your exact target offset, including the flush or max specs above, so you get the correct fitment without stacking spacers. Spacers are typically only used to push out an existing OE-offset wheel without replacing it, which isn't necessary when you're ordering a custom-offset forged wheel.
How do I calculate wheel backspacing for my Dodge Grand Caravan?
Backspacing (in inches) = wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance). For example, the flush spec above works out to roughly 6.07" of backspacing.
What's the difference between wheel offset and backspacing?
Offset is the distance in millimeters from the wheel's true centerline to its mounting face (positive offset pulls the wheel in, negative pushes it out). Backspacing is the distance in inches from the mounting face to the back edge of the wheel barrel. They describe the same fitment from two different reference points, which is why ANKUSI lists both above — some shops and tuning guides quote offset, others quote backspacing.
Can I run staggered wheels (different sizes front and rear) on my Dodge Grand Caravan?
The Dodge Grand Caravan runs the same wheel size front and rear from the factory, so staggered fitment is not required. ANKUSI can still forge a staggered set (wider rear) on request if you want a more aggressive stance.
