Lincoln Aviator Bolt Pattern, Center Bore & Wheel Offset (2003–2025)
Lincoln Aviator wheel fitment: 5x114.3 bolt pattern, 70.5mm center bore (2003–2025). OE wheel sizes and offsets for every Aviator variant we cover (2 guides),
- 5x114.3bolt pattern (PCD)
- 70.5 mmcenter bore
- M12x1.5 Nutwheel bolt / nut
- 2 guidesmodel years 2003–2025
Lincoln Aviator wheel specs by year and trim
| Year | Model / trim | Bolt pattern | Center bore | OE wheel |
|---|---|---|---|---|
| 2025 | Lincoln Aviator | 5x114.3 | 70.5 mm | 22x9.5J ET38 |
| 2005 | Lincoln Aviator | 5x114.3 | 70.5 mm | 17x7.5J ET44 |
Factory wheel sizes on the Lincoln Aviator
Across the 2 Lincoln Aviator trims with a documented factory wheel, the OE diameter is 17-22 inch, width 7.5-9.5J and offset ET38-44. A forged wheel that keeps the 5x114.3 bolt pattern and the 70.5 mm hub bore and stays inside that offset range bolts on without spacers or hub rings. Going one inch up in diameter with a lower-profile tyre keeps the rolling circumference inside the usual 1.5% tolerance; every extra 0.5J of width moves the outer lip about 6 mm outward at the same offset, and each 5 mm less offset moves the whole wheel 5 mm outward.
Forged wheels for the Lincoln Aviator (5x114.3)
Shop all Lincoln Aviator forged wheels →
Get a quote for Lincoln Aviator wheels
Vehicles With the Same Hub as the Lincoln Aviator (5x114.3, 70.5 mm Bore)
In our database, 151 other vehicle entries from 5 makes use exactly the same 5x114.3 bolt pattern and 70.5 mm center bore. Factory wheels from these cars bolt on and center on the hub without rings; offset and width still have to be checked.
5x114.3 is used by 20.0% of the vehicle entries in our database (1,303 of 6,503); 12.0% of those also use a 70.5 mm center bore.
Hub-Centric Rings for a 70.5 mm Center Bore
A wheel with a center bore larger than 70.5 mm needs a hub-centric ring. The most common combinations:
| Wheel bore | Ring size |
|---|---|
| 71.6 mm | 71.6 → 70.5 mm |
| 72.6 mm | 72.6 → 70.5 mm |
| 73.1 mm | 73.1 → 70.5 mm |
| 74.1 mm | 74.1 → 70.5 mm |
ANKUSI forged wheels are bored to exactly 70.5 mm for this vehicle, so no ring is needed.
Sources and Last Update
Bolt pattern and center bore were checked against at least two independent fitment references before publication.
This record is part of the open ANKUSI Wheel Fitment Dataset (DOI 10.5281/zenodo.23241521, CC BY 4.0).
Compiled by the ANKUSI Wheels engineering team, an IATF 16949 and ISO 9001 certified forged wheel factory in Guangzhou.
FAQ
What is the bolt pattern on a Lincoln Aviator?
The Lincoln Aviator uses a 5x114.3 bolt pattern with a 70.5mm center bore across every Aviator variant in our database (2 guides, 2003–2025).
What is the Lincoln Aviator center bore?
The hub-centric center bore is 70.5 mm. Aftermarket wheels should match this bore or use hub-centric rings so the hub, not the bolts, carries the load.
Do all Lincoln Aviator years share the same wheel fitment?
The bolt pattern and center bore are the same across the years we cover, but OE wheel width and offset differ by trim, so check the exact model line before choosing an aftermarket size.
Which forged wheels fit the Lincoln Aviator?
Any wheel drilled 5x114.3 with a 70.5mm hub bore in the offset range shown on the model guide. ANKUSI forges wheels to order for this exact specification, in 14–24 inch diameters, so no adapters or hub rings are needed.
