Forged wheels for the Tesla Model 3 featuring the vossen HF-2-style gloss black / gunmetal petal design. Each wheel is forged from a solid 6061-T6 aluminium billet on ANKUSI's own 10,000-tonne press in Guangzhou, then CNC-machined, heat-treated and finished in-house under IATF 16949 and ISO 9001.
Design details
As a one-piece monoblock it is machined from a single forging, the lightest and stiffest construction we make. It is supplied with a plain centre cap, or with your own logo on request. Drilled for 5-lug hubs (5x112, 5x114.3 as listed below), with diameter from 14 to 24 inch depending on brake clearance. See more vossen-style forged wheels, vossen hf-2-style forged wheels, petal forged wheels.
Fitment
Commonly ordered for Tesla Model 3 (5x114.3, 64.1mm centre bore); Audi A5 (5x112, 66.5mm centre bore). Every set is cut to order, so we machine the bolt pattern, centre bore and offset to match your car exactly — send us the year, model and brake setup and we confirm the spec before anything is cut.
Specification
- Construction: forged 6061-T6 aluminium
- Load rating: 950–1,750 kg (2,094–3,858 lb) per wheel, set to your vehicle's axle load when the wheel is specified
- Bolt pattern: 5-lug, machined to order
- Diameter and width: cut to order
- Offset: calculated for your vehicle, flush to aggressive
- Finish: Gloss Black / Gunmetal
Single sets through to full container orders. Tell us your vehicle and the stance you are after and we will quote.
Tesla Model 3 wheels and Audi A5 wheels: bolt patterns this design is cut for
This Vossen HF-2-Style Gloss Black / Gunmetal Petal design is forged blank and machined to order, so the same wheel is made as 5x112 wheels or 5x114.3 wheels with the centre bore, width and offset your car needs. The vehicles below share the bolt pattern. Send us your year and model and we confirm the exact spec before production.
- Tesla Model 3 wheels – 5x114.3, 64.1 mm centre bore
- Audi A5 wheels – 5x112, 66.5 mm centre bore
- Audi A4 B9 – 5x112, 66.5 mm centre bore (factory 19x8.5J F/R)
- Audi A6 C8 – 5x112, 66.5 mm centre bore (factory 19x8.5J F/R)
- Audi RS3 8Y – 5x112, 57.1 mm centre bore (factory F: 19x9.0J R: 19x8.0J)
- Tesla Model Y – 5x114.3, 64.1 mm centre bore (factory F: 21x9.5J R: 21x10.5J)
- Ford Mustang S550 – 5x114.3, 70.5 mm centre bore (factory F: 19x9.5J R: 19x10.0J)
- Subaru WRX – 5x114.3, 56.1 mm centre bore (factory 18x8.5J at ET55 offset, front and rear)
- FM Auto Vulca – 5x114.3, 67.1 mm centre bore (factory F: 19x8.5J R: 19x10.0J)
- Renault Symbioz – 5x114.3, 66.1 mm centre bore
- Infiniti FX37 – 5x114.3, 66.1 mm centre bore (factory 20x8J ET50)
Shipping and returns
Shipping costs about US$230–260 to the United States and US$250–300 to Europe; the exact figure is confirmed in your quotation. Wheels are forged to order, so they are not returnable, but if a wheel has a quality problem caused by the wheel itself we make and ship a new one at our cost. Shipping and returns details.
