Chevrolet Corvette Wheels & Rims, Forged to Order

Forged Chevrolet Corvette wheels and rims are listed here, in 14 to 24 inch diameters. Each one is forged to order from 6061-T6 aluminium and machined to your generation's bolt pattern and centre bore, with width and offset calculated for the stance you want: factory-flush, flush or aggressive.

Finishes in this collection: Gloss Black / Machined, Gloss Black, Gunmetal, Matte Silver, Chrome, Gloss Black / Mirror Milled. Reference price from $220 per wheel; final quote depends on size, finish and quantity.

Corvette C8 Stingray setups and pricesCorvette C8 Z06 setups and prices

Chevrolet Corvette wheel specs by generation

Model / yearBolt patternCenter boreFactory wheels
Chevrolet Corvette Grand Sport (2027)5x12066.9 mmF: 20x10.0J R: 21x13.0J
Corvette Grand Sport X (2027)5x12066.9 mmF 20x10.0J ET40 / R 21x13.0J ET50
Chevrolet Corvette Grand Sport X (2027)5x12066.9 mmF: 20x10.0J R: 21x13.0J
Chevrolet Corvette ZR1X (2026)5x12066.9 mmF: 20x10.0J R: 21x13.0J
Chevrolet Corvette ZR1X Quail Silver Limited Edition (2026)5x12066.9 mmF: 20x10.0J R: 21x13.0J
Chevrolet Corvette C8 Convertible (UK) (2025)5x12066.9 mmF: 19x8.5J R: 20x11.0J
Chevrolet Corvette Z06 Coupe (UK) (2025)5x12066.9 mmF: 20x10.0J R: 21x13.0J
Chevrolet Corvette ZR1 (2025)5x12066.9 mmF: 20x10.0J R: 21x13.0J
Chevrolet Corvette E-Ray (2024)5x12066.9 mmF: 20x10.0J R: 21x13.0J
Chevrolet Corvette E-Ray Convertible (2024)5x12066.9 mmF: 20x10.0J R: 21x13.0J

Data from our fitment database. Open a row for flush and maximum sizes, offsets and FAQs.

Chevrolet wheel fitment guide: bolt pattern, center bore and offset for every model →

Designs 1–48 of 68

Browse more collections

Chevrolet Forged WheelsChevrolet Silverado Wheels & Rims, Forged to OrderChevrolet Camaro Wheels & Rims, Forged to OrderToyota GR86 Wheels & Rims, Forged to OrderTesla Model Y Wheels & Rims, Forged to OrderTesla Model 3 Wheels & Rims, Forged to OrderAudi RS3 Wheels & Rims, Forged to OrderBMW M4 Wheels & Rims, Forged to OrderVolkswagen Tiguan Wheels & Rims, Forged to OrderHonda Civic Type R Wheels & Rims, Forged to OrderAudi R8 Wheels & Rims, Forged to OrderLamborghini Aventador Wheels & Rims, Forged to OrderSubaru WRX Wheels & Rims, Forged to OrderBMW M2 Wheels & Rims, Forged to OrderBronze Forged WheelsGloss Black Forged WheelsY-Spoke Forged WheelsDeep Lip Forged WheelsConcave Forged Wheels2-Piece Forged Wheels

Vehicles With the Same Hub as the Chevrolet Corvette (5x120, 66.9 mm Bore)

In our database, 121 other vehicle entries from 9 makes use exactly the same 5x120 bolt pattern and 66.9 mm center bore. Factory wheels from these cars bolt on and center on the hub without rings; offset and width still have to be checked.

5x120 is used by 10.3% of the vehicle pages in our English fitment guide (670 of 6,503); 24.2% of those also use a 66.9 mm center bore.

Hub-Centric Rings for a 66.9 mm Center Bore

A wheel with a center bore larger than 66.9 mm needs a hub-centric ring. The most common combinations:

Wheel boreRing size
67.1 mm67.1 → 66.9 mm
70.1 mm70.1 → 66.9 mm
70.5 mm70.5 → 66.9 mm
71.6 mm71.6 → 66.9 mm
73.1 mm73.1 → 66.9 mm

ANKUSI forged wheels are bored to exactly 66.9 mm for this vehicle, so no ring is needed.

Sources and Last Update

Bolt pattern and center bore were checked against at least two independent fitment references before publication.

This record is part of the open ANKUSI Wheel Fitment Dataset (DOI 10.5281/zenodo.23241521, CC BY 4.0).

Compiled by the ANKUSI Wheels engineering team, an IATF 16949 and ISO 9001 certified forged wheel factory in Guangzhou.
