Pontiac Vibe Bolt Pattern, Center Bore & Wheel Offset (2005–2010)
Pontiac Vibe wheel fitment: 5x100 bolt pattern, 54.1mm center bore (2005–2010). OE wheel sizes and offsets for every Vibe variant we cover (4 guides), plus fl
- 5x100bolt pattern (PCD)
- 54.1 mmcenter bore
- Nutwheel bolt / nut
- 4 guidesmodel years 2005–2010
Pontiac Vibe wheel specs by year and trim
| Year | Model / trim | Bolt pattern | Center bore | OE wheel |
|---|---|---|---|---|
| 2010 | Pontiac Vibe | 5x100 | 54.1 mm | 16x6.5J |
| 2009 | Pontiac Vibe | 5x100 | 54.1 mm | 16x6.5J |
| 2008 | Pontiac Vibe | 5x100 | 54.1 mm | 16x6.5J |
| 2005 | Pontiac Vibe | 5x100 | 54.1 mm | 16x6.5J |
Factory wheel sizes on the Pontiac Vibe
Across the 4 Pontiac Vibe trims with a documented factory wheel, the OE diameter is 16 inch, width 6.5J. A forged wheel that keeps the 5x100 bolt pattern and the 54.1 mm hub bore and matches the factory offset listed on the model page bolts on without spacers or hub rings. Going one inch up in diameter with a lower-profile tyre keeps the rolling circumference inside the usual 1.5% tolerance; every extra 0.5J of width moves the outer lip about 6 mm outward at the same offset, and each 5 mm less offset moves the whole wheel 5 mm outward.
Forged wheels for the Pontiac Vibe (5x100)
Get a quote for Pontiac Vibe wheels
Vehicles With the Same Hub as the Pontiac Vibe (5x100, 54.1 mm Bore)
In our database, 16 other vehicle entries from 3 makes use exactly the same 5x100 bolt pattern and 54.1 mm center bore. Factory wheels from these cars bolt on and center on the hub without rings; offset and width still have to be checked.
5x100 is used by 1.9% of the vehicle entries in our database (123 of 6,396); 13.8% of those also use a 54.1 mm center bore.
Hub-Centric Rings for a 54.1 mm Center Bore
A wheel with a center bore larger than 54.1 mm needs a hub-centric ring. The most common combinations:
| Wheel bore | Ring size |
|---|---|
| 56.1 mm | 56.1 → 54.1 mm |
| 57.1 mm | 57.1 → 54.1 mm |
| 60.1 mm | 60.1 → 54.1 mm |
| 63.4 mm | 63.4 → 54.1 mm |
| 73.1 mm | 73.1 → 54.1 mm |
ANKUSI forged wheels are bored to exactly 54.1 mm for this vehicle, so no ring is needed.
Sources and Last Update
Bolt pattern and center bore were checked against at least two independent fitment references before publication.
This record is part of the open ANKUSI Wheel Fitment Dataset (DOI 10.5281/zenodo.23241521, CC BY 4.0).
Compiled by the ANKUSI Wheels engineering team, an IATF 16949 and ISO 9001 certified forged wheel factory in Guangzhou.
FAQ
What is the bolt pattern on a Pontiac Vibe?
The Pontiac Vibe uses a 5x100 bolt pattern with a 54.1mm center bore across every Vibe variant in our database (4 guides, 2005–2010).
What is the Pontiac Vibe center bore?
The hub-centric center bore is 54.1 mm. Aftermarket wheels should match this bore or use hub-centric rings so the hub, not the bolts, carries the load.
Do all Pontiac Vibe years share the same wheel fitment?
The bolt pattern and center bore are the same across the years we cover, but OE wheel width and offset differ by trim, so check the exact model line before choosing an aftermarket size.
Which forged wheels fit the Pontiac Vibe?
Any wheel drilled 5x100 with a 54.1mm hub bore in the offset range shown on the model guide. ANKUSI forges wheels to order for this exact specification, in 14–24 inch diameters, so no adapters or hub rings are needed.
