2020 Toyota ProAce City Verso Wheels & Rims: Bolt Pattern, Offset & Sizes

Fitting Toyota ProAce City Verso wheels? This page gives the 2020 Toyota ProAce City Verso bolt pattern (5x108), centre bore, factory rim size and the offset range for aftermarket and forged Toyota ProAce City Verso rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.

Toyota ProAce City Verso (2020): 5x108 bolt pattern, 65.1mm center bore. Factory wheels: F/R: 16x6.5J at ET47 offset, front and rear. Reference fitment ranges.

Bolt Pattern5x108
Wheel Bolt/NutM12x1.25 Nut
Center Bore65.1mm
Wheel Load Rating900–1100 kg/wheel (Van / MPV segment reference)
Year2020
CategoryCompact MPV

✓ Data check: the bolt pattern and center bore on this page match an independent fitment reference. Last reviewed September 18, 2026. How we verify

Use this spec on your site

Paste this code into a forum post, listing or web page to show the Toyota ProAce City Verso 2020 bolt pattern, center bore and factory wheel size. Free, no sign-up.

<iframe src="https://ankusiwheels.com/wp-content/uploads/ankusi-embed/lookup.html?vehicle=toyota-proace-city-verso&card=1" width="100%" height="230" style="border:0;max-width:560px" loading="lazy" title="Toyota ProAce City Verso 2020 bolt pattern"></iframe>
<p style="font-size:13px"><a href="https://ankusiwheels.com/fitment-guide/toyota-proace-city-verso/">Toyota ProAce City Verso 2020 bolt pattern and offset guide</a> by ANKUSI Wheels</p>

More free tools: bolt pattern lookup and offset calculator for your website.

Wheel Size & Offset at a Glance

Toyota ProAce City Verso wheel size and offset comparison by configuration
ConfigurationWheel Size & Offset
Factory (OE)F/R: 16x6.5J F/R
Flush Fitment17x7.5J at ET38 offset
Maximum Aggressive18x8.0J at ET35 offset

Forged Wheel Designs for the Toyota ProAce City Verso

Every design below is forged to order, so it can be machined to the Toyota ProAce City Verso's 5x108 bolt pattern and 65.1 mm center bore, with the width and offset calculated for your setup.

How to Read Wheel Offset & Measurements

Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.

Diagram showing wheel measurement points: centerline, center bore diameter, PCD, offset, rim width and diameter
Centerline, center bore, PCD, offset, width & diameter
Diagram comparing positive, zero, and negative wheel offset relative to the wheel centerline
Positive vs. zero vs. negative offset

ANKUSI Engineering Expert Advice

A minivan's wheel spec has to work across a wide load range — empty commute or full family trip. Forged construction preserves the factory's load-rating margin while cutting rotational weight, which keeps ride quality consistent across that range.

The Toyota ProAce City Verso runs a 5x108 bolt pattern, 65.1mm center bore, and a 16x6.5J, front and rear, wheel from the factory. Our Flush Fitment reference is 17x7.5J ET38, which tucks the tire under the fender lip on a stock-height Toyota ProAce City Verso. Our Maximum Aggressive reference is 18x8.0J ET35 — beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.

Toyota ProAce City Verso OE Wheel Specs

The 2020 Toyota ProAce City Verso (Compact MPV) uses a 5x108 bolt pattern with a 65.1mm center bore. Factory wheels are F/R: 16x6.5J F/R.

Why the factory spec works for most owners:

  • Balances ride comfort with everyday drivability
  • A commonly used size for this vehicle class, supporting parts and tire availability
  • Maintains clearance for the factory suspension and brake components
  • Provides stable, predictable handling across normal driving conditions

ANKUSI builds these wheels — we are the forging factory, not a reseller. For the Toyota ProAce City Verso (2020) we drill the 5x108 pattern and cut the centre bore to 65.1mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.

IATF 16949 & ISO 9001 certified · own 10,000-ton press in Guangzhou · from a single set to a full container

Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.

The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.

Offset & Backspacing Reference

Backspacing is calculated as wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance):

  • OE: F/R: 16x6.5J ET47 → ~5.6″ backspacing
  • Flush: 17x7.5J ET38 → ~5.75″ backspacing
  • Max: 18x8.0J ET35 → ~5.88″ backspacing

A Note on Clearance

Final clearance depends on the exact tire model, suspension height, brake package, alignment and vehicle tolerances. A physical test fit is recommended before production.

Want to check a different width or offset before you order? Use our Offset & Backspacing Calculator to solve the numbers yourself, or looking for your exact Toyota spec, or want a wheel built to a custom offset for your Toyota ProAce City Verso? Contact ANKUSI with your bolt pattern and offset target and we will confirm the correct forged wheel spec for your build.

Frequently Asked Questions

What bolt pattern (PCD) does the Toyota ProAce City Verso use?
The 2020 Toyota ProAce City Verso uses a 5x108 bolt pattern.
How many lug bolts does the Toyota ProAce City Verso use?
The Toyota ProAce City Verso uses a 5-lug bolt pattern (5x108), so you need a 5-lug forged wheel to bolt straight on.
What is the center bore size on the Toyota ProAce City Verso?
The Toyota ProAce City Verso's center bore is 65.1mm. If an aftermarket wheel has a larger center bore than this, hub-centric rings are recommended so the wheel centers on the hub itself rather than relying on the lug bolts alone.
What size are the factory (stock) wheels on the Toyota ProAce City Verso?
Factory wheels on the Toyota ProAce City Verso are F/R: 16x6.5J F/R.
What is the biggest wheel size I can fit on my Toyota ProAce City Verso without rubbing?
The most aggressive fitment we recommend without fender work is 18x8.0J at ET35 offset. Going beyond this typically causes rubbing under compression unless you roll the fenders or add camber correction.
What does a flush wheel fitment look like on the Toyota ProAce City Verso?
For a flush look with minimal to no rubbing, we recommend 17x7.5J at ET38 offset as a starting point on a stock or mildly lowered Toyota ProAce City Verso.
Do I need wheel spacers for my Toyota ProAce City Verso?
No. ANKUSI forges each wheel to your exact target offset, including the flush or max specs above, so you get the correct fitment without stacking spacers. Spacers are typically only used to push out an existing OE-offset wheel without replacing it, which isn't necessary when you're ordering a custom-offset forged wheel.
How do I calculate wheel backspacing for my Toyota ProAce City Verso?
Backspacing (in inches) = wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance). For example, the flush spec above works out to roughly 5.75" of backspacing.
What's the difference between wheel offset and backspacing?
Offset is the distance in millimeters from the wheel's true centerline to its mounting face (positive offset pulls the wheel in, negative pushes it out). Backspacing is the distance in inches from the mounting face to the back edge of the wheel barrel. They describe the same fitment from two different reference points, which is why ANKUSI lists both above — some shops and tuning guides quote offset, others quote backspacing.
Can I run staggered wheels (different sizes front and rear) on my Toyota ProAce City Verso?
The Toyota ProAce City Verso runs the same wheel size front and rear from the factory, so staggered fitment is not required. ANKUSI can still forge a staggered set (wider rear) on request if you want a more aggressive stance.
