2026 Nissan X-Trail Wheels & Rims: Bolt Pattern, Offset & Sizes
Fitting Nissan X-Trail wheels? This page gives the 2026 Nissan X-Trail bolt pattern (5x114.3), centre bore, factory rim size and the offset range for aftermarket and forged Nissan X-Trail rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.
Quick answer: The 2026 Nissan X-Trail uses a 5x114.3 bolt pattern with a 66.1 mm centre bore and M12x1.25 lug nuts. Factory wheels: 19x7.5J at ET45, front and rear. For aftermarket wheels, 20x8.5J ET35 sits flush and 21x9.0J ET30 is the most aggressive fit.
Forged wheels for the 2026 Nissan X-Trail — drilled 5x114.3 with a 66.1 mm centre bore, built to the offset you choose. From $220 per wheel, made to order in 20–25 days.
Get a quote for this car
Nissan X-Trail (2026): 5x114.3 bolt pattern, 66.1mm center bore. Factory wheels: 19x7.5J at ET45 offset, front and rear. Reference fitment ranges.
Bolt Pattern5x114.3
Wheel Bolt/NutM12x1.25 Nut
Center Bore66.1mm
Wheel Load Rating900–1250 kg/wheel (SUV segment reference)
Year2026
Category5-Lug Large Sedan/SUV (Thick Spokes, Large Size)
✓ Data check: the bolt pattern and center bore on this page match an independent fitment reference. Last reviewed September 25, 2026. How we verify
Wheel Size & Offset at a Glance
| Configuration | Wheel Size & Offset |
|---|---|
| Factory (OE) | 19x7.5J at ET45 offset, front and rear |
| Flush Fitment | 20x8.5J at ET35 offset |
| Maximum Aggressive | 21x9.0J at ET30 offset |
Forged Wheel Designs for the Nissan X-Trail
Every design below is forged to order, so it can be machined to the Nissan X-Trail's 5x114.3 bolt pattern and 66.1 mm center bore, with the width and offset calculated for your setup.
Work Meister S1 3P Matte Black Riveted Deep Dish Lip 3-Piece Forged Wheels
2-Piece · Matte Black
Rays-Style Matte Bronze 10-Spoke Forged Wheels
Monoblock · Matte Bronze
Chrome 5 Y-Spoke Forged Wheels
Monoblock · Chrome
Rays-Style Gloss Black 10 Y-Spoke Polished Deep Lip Forged Wheels
Deep Dish · Gloss Black
Black 9-Spoke Forged Wheels
Monoblock · Black
Nissan OEM-Style Chrome 5-Spoke Black Ring Beadlock Forged Wheels
Off-Road Beadlock · Chrome / Black Ring
Rays-Style Bronze 6 Y-Spoke Racing Forged Wheels
Replica · Bronze
How to Read Wheel Offset & Measurements
Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.
ANKUSI Engineering Expert Advice
SUVs carry more curb weight higher off the ground, so wheel strength and rotational mass both matter more than on a comparable sedan — a heavier wheel amplifies body roll and slows steering response exactly where the platform is already working hardest. Forging keeps the wheel light without giving up the load rating the factory suspension geometry was tuned around.
The Nissan X-Trail runs a 5x114.3 bolt pattern, 66.1mm center bore, and a 19x7.5J at ET45, front and rear, wheel from the factory. Our Flush Fitment reference is 20x8.5J, which tucks the tire under the fender lip on a stock-height Nissan X-Trail. Our Maximum Aggressive reference is 21x9.0J at ET30 — beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.
Nissan X-Trail OE Wheel Specs
The 2026 Nissan X-Trail (SUV) uses a 5x114.3 bolt pattern with a 66.1mm center bore. Factory wheels are 19x7.5J at ET45 offset, front and rear.
Why the factory spec works for most owners:
- Supports the vehicle's curb weight and load capacity
- Preserves ground clearance for everyday and light off-road use
- Balances ride comfort with cargo and passenger stability
- Maintains clearance for the factory suspension travel and brake package
ANKUSI builds these wheels — we are the forging factory, not a reseller. For the Nissan X-Trail (2026) we drill the 5x114.3 pattern and cut the centre bore to 66.1mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.
Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.
The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.
Nissan X-Trail: Specs by Model Year
| Year | Bolt pattern | Center bore | Factory wheel |
|---|---|---|---|
| 2008 | 5x114.3 | 66.1 mm | 17x7J ET45 |
| 2011 | 5x114.3 | 66.1 mm | 18x7J ET45 |
| 2014 | 5x114.3 | 66.1 mm | 18x7J ET45 |
| 2018 | 5x114.3 | 66.1 mm | 19x7J ET45 |
| 2023 | 5x114.3 | 66.1 mm | 19x7.5J ET45 |
| 2026 | 5x114.3 | 66.1 mm | 19x7.5J ET45 |
Bolt pattern and center bore stay the same across all 6 model years in our database (2008–2026).
Offset and Backspacing: Factory Wheel vs Options
Backspacing ≈ width/2 + ET/25.4 + 0.5 in. "Inward" means closer to the suspension; "outward" means closer to the fender lip.
| Setup | Size | ET | Backspacing | Inward vs OE | Outward vs OE |
|---|---|---|---|---|---|
| Factory (OE) | 19x7.5J | ET45 | 6.02 in (153 mm) | — | — |
| Maximum | 21x9J | ET30 | 6.18 in (157 mm) | +4 mm | +34 mm |
Vehicles With the Same Hub as the Nissan X-Trail (5x114.3, 66.1 mm Bore)
In our database, 222 other vehicle entries from 9 makes use exactly the same 5x114.3 bolt pattern and 66.1 mm center bore. Factory wheels from these cars bolt on and center on the hub without rings; offset and width still have to be checked.
5x114.3 is used by 20.0% of the vehicle pages in our English fitment guide (1,300 of 6,503); 17.3% of those also use a 66.1 mm center bore.
Hub-Centric Rings for a 66.1 mm Center Bore
A wheel with a center bore larger than 66.1 mm needs a hub-centric ring. The most common combinations:
| Wheel bore | Ring size |
|---|---|
| 66.6 mm | 66.6 → 66.1 mm |
| 67.1 mm | 67.1 → 66.1 mm |
| 70.1 mm | 70.1 → 66.1 mm |
| 70.5 mm | 70.5 → 66.1 mm |
| 73.1 mm | 73.1 → 66.1 mm |
ANKUSI forged wheels are bored to exactly 66.1 mm for this vehicle, so no ring is needed.
Frequently Asked Questions
What bolt pattern (PCD) does the Nissan X-Trail use?
The 2026 Nissan X-Trail uses a 5x114.3 bolt pattern.
How many lug bolts does the Nissan X-Trail use?
The Nissan X-Trail uses a 5-lug bolt pattern (5x114.3), so you need a 5-lug forged wheel to bolt straight on.
What is the center bore size on the Nissan X-Trail?
The Nissan X-Trail's center bore is 66.1mm. If an aftermarket wheel has a larger center bore than this, hub-centric rings are recommended so the wheel centers on the hub itself rather than relying on the lug bolts alone.
What size are the factory (stock) wheels on the Nissan X-Trail?
Factory wheels on the Nissan X-Trail are 19x7.5J at ET45 offset, front and rear.
What is the biggest wheel size I can fit on my Nissan X-Trail without rubbing?
The most aggressive fitment we recommend without fender work is 21x9.0J at ET30 offset. Going beyond this typically causes rubbing under compression unless you roll the fenders or add camber correction.
What does a flush wheel fitment look like on the Nissan X-Trail?
For a flush look with minimal to no rubbing, we recommend 20x8.5J at ET35 offset as a starting point on a stock or mildly lowered Nissan X-Trail.
Do I need wheel spacers for my Nissan X-Trail?
No. ANKUSI forges each wheel to your exact target offset, including the flush or max specs above, so you get the correct fitment without stacking spacers. Spacers are typically only used to push out an existing OE-offset wheel without replacing it, which isn't necessary when you're ordering a custom-offset forged wheel.
How do I calculate wheel backspacing for my Nissan X-Trail?
Backspacing (in inches) = wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance). For example, the flush spec above works out to roughly 6.13" of backspacing.
What's the difference between wheel offset and backspacing?
Offset is the distance in millimeters from the wheel's true centerline to its mounting face (positive offset pulls the wheel in, negative pushes it out). Backspacing is the distance in inches from the mounting face to the back edge of the wheel barrel. They describe the same fitment from two different reference points, which is why ANKUSI lists both above — some shops and tuning guides quote offset, others quote backspacing.
Can I run staggered wheels (different sizes front and rear) on my Nissan X-Trail?
The Nissan X-Trail runs the same wheel size front and rear from the factory, so staggered fitment is not required. ANKUSI can still forge a staggered set (wider rear) on request if you want a more aggressive stance.
Wheel Installation Reference: Torque, Thread & TPMS
Thread & Fastener: M12x1.25, conical-seat lug nut.
Factory Torque Spec: 103-122 Nm (76-90 ft-lb). Range covers most Nissan passenger cars and crossovers on M12x1.25 studs.
TPMS: TPMS (Tire Pressure Monitoring System) has been federally mandated on all new light vehicles sold in the US since the 2008 model year. If your wheels use OE-style sensors, have them transferred or cloned to the new wheels at installation.
Tire Pressure: Always set tire pressure to the value on your vehicle's tire placard (driver's doorjamb or glovebox), not the max PSI printed on the tire sidewall — this is trim- and tire-size-specific and stays the same reference point when you switch to a different wheel and tire combination.
Reference data compiled from published OEM service specifications and cross-checked against independent repair sources; always confirm against your owner's manual or door-jamb placard before installation.
