2007 Nissan Qashqai Wheels & Rims: Bolt Pattern, Offset & Sizes

Fitting Nissan Qashqai wheels? This page gives the 2007 Nissan Qashqai bolt pattern (5x114.3), centre bore, factory rim size and the offset range for aftermarket and forged Nissan Qashqai rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.

Nissan Qashqai (2007): 5x114.3 bolt pattern, 66.1mm center bore. Factory wheels: 16x6.5J at ET40 offset, front and rear. Reference fitment ranges.

Bolt Pattern5x114.3
Wheel Bolt/NutM12x1.25 Nut
Center Bore66.1mm
Wheel Load Rating800–950 kg/wheel (Crossover segment reference)
Year2007
CategoryCrossover

✓ Data check: the bolt pattern and center bore on this page match an independent fitment reference. Last reviewed September 18, 2026. How we verify

Use this spec on your site

Paste this code into a forum post, listing or web page to show the Nissan Qashqai 2007 bolt pattern, center bore and factory wheel size. Free, no sign-up.

<iframe src="https://ankusiwheels.com/wp-content/uploads/ankusi-embed/lookup.html?vehicle=nissan-qashqai-2007&card=1" width="100%" height="230" style="border:0;max-width:560px" loading="lazy" title="Nissan Qashqai 2007 bolt pattern"></iframe>
<p style="font-size:13px"><a href="https://ankusiwheels.com/fitment-guide/nissan-qashqai-2007/">Nissan Qashqai 2007 bolt pattern and offset guide</a> by ANKUSI Wheels</p>

More free tools: bolt pattern lookup and offset calculator for your website.

Wheel Size & Offset at a Glance

Nissan Qashqai wheel size and offset comparison by configuration
ConfigurationWheel Size & Offset
Factory (OE)16x6.5J F/R
Flush Fitment18x8.0J at ET32 offset
Maximum Aggressive19x8.5J at ET28 offset

Forged Wheel Designs for the Nissan Qashqai

Every design below is forged to order, so it can be machined to the Nissan Qashqai's 5x114.3 bolt pattern and 66.1 mm center bore, with the width and offset calculated for your setup.

How to Read Wheel Offset & Measurements

Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.

Diagram showing wheel measurement points: centerline, center bore diameter, PCD, offset, rim width and diameter
Centerline, center bore, PCD, offset, width & diameter
Diagram comparing positive, zero, and negative wheel offset relative to the wheel centerline
Positive vs. zero vs. negative offset

ANKUSI Engineering Expert Advice

The Nissan Qashqai's factory suspension tuning already accounts for a specific unsprung mass target. Forged construction lets ANKUSI match the factory strength spec while keeping rotational weight down, which is where the real handling benefit comes from on a taller, heavier SUV platform.

The Nissan Qashqai runs a 5x114.3 bolt pattern, 66.1mm center bore, and a 16x6.5J, front and rear, wheel from the factory. Our Flush Fitment reference is 18x8.0J ET32, which tucks the tire under the fender lip on a stock-height Nissan Qashqai. Our Maximum Aggressive reference is 19x8.5J ET28 — beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.

Nissan Qashqai OE Wheel Specs

The 2007 Nissan Qashqai (Crossover) uses a 5x114.3 bolt pattern with a 66.1mm center bore. Factory wheels are 16x6.5J F/R.

Why the factory spec works for most owners:

  • Supports the vehicle's curb weight and load capacity
  • Preserves ground clearance for everyday and light off-road use
  • Balances ride comfort with cargo and passenger stability
  • Maintains clearance for the factory suspension travel and brake package

ANKUSI builds these wheels — we are the forging factory, not a reseller. For the Nissan Qashqai (2007) we drill the 5x114.3 pattern and cut the centre bore to 66.1mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.

IATF 16949 & ISO 9001 certified · own 10,000-ton press in Guangzhou · from a single set to a full container

Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.

The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.

Offset & Backspacing Reference

Backspacing is calculated as wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance):

  • OE: 16x6.5J ET40 → ~5.32″ backspacing
  • Flush: 18x8.0J ET32 → ~5.76″ backspacing
  • Max: 19x8.5J ET28 → ~5.85″ backspacing

A Note on Clearance

Final clearance depends on the exact tire model, suspension height, brake package, alignment and vehicle tolerances. A physical test fit is recommended before production.

Want to check a different width or offset before you order? Use our Offset & Backspacing Calculator to solve the numbers yourself, or looking for your exact Nissan spec, or want a wheel built to a custom offset for your Nissan Qashqai? Contact ANKUSI with your bolt pattern and offset target and we will confirm the correct forged wheel spec for your build.

Frequently Asked Questions

What bolt pattern (PCD) does the Nissan Qashqai use?
The 2007 Nissan Qashqai uses a 5x114.3 bolt pattern.
How many lug bolts does the Nissan Qashqai use?
The Nissan Qashqai uses a 5-lug bolt pattern (5x114.3), so you need a 5-lug forged wheel to bolt straight on.
What is the center bore size on the Nissan Qashqai?
The Nissan Qashqai's center bore is 66.1mm. If an aftermarket wheel has a larger center bore than this, hub-centric rings are recommended so the wheel centers on the hub itself rather than relying on the lug bolts alone.
What size are the factory (stock) wheels on the Nissan Qashqai?
Factory wheels on the Nissan Qashqai are 16x6.5J F/R.
What is the biggest wheel size I can fit on my Nissan Qashqai without rubbing?
The most aggressive fitment we recommend without fender work is 19x8.5J at ET28 offset. Going beyond this typically causes rubbing under compression unless you roll the fenders or add camber correction.
What does a flush wheel fitment look like on the Nissan Qashqai?
For a flush look with minimal to no rubbing, we recommend 18x8.0J at ET32 offset as a starting point on a stock or mildly lowered Nissan Qashqai.
Do I need wheel spacers for my Nissan Qashqai?
No. ANKUSI forges each wheel to your exact target offset, including the flush or max specs above, so you get the correct fitment without stacking spacers. Spacers are typically only used to push out an existing OE-offset wheel without replacing it, which isn't necessary when you're ordering a custom-offset forged wheel.
How do I calculate wheel backspacing for my Nissan Qashqai?
Backspacing (in inches) = wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance). For example, the flush spec above works out to roughly 5.76" of backspacing.
What's the difference between wheel offset and backspacing?
Offset is the distance in millimeters from the wheel's true centerline to its mounting face (positive offset pulls the wheel in, negative pushes it out). Backspacing is the distance in inches from the mounting face to the back edge of the wheel barrel. They describe the same fitment from two different reference points, which is why ANKUSI lists both above — some shops and tuning guides quote offset, others quote backspacing.
Can I run staggered wheels (different sizes front and rear) on my Nissan Qashqai?
The Nissan Qashqai runs the same wheel size front and rear from the factory, so staggered fitment is not required. ANKUSI can still forge a staggered set (wider rear) on request if you want a more aggressive stance.

Wheel Installation Reference: Torque, Thread & TPMS

Thread & Fastener: M12x1.25, conical-seat lug nut.

Factory Torque Spec: 103-122 Nm (76-90 ft-lb). Range covers most Nissan passenger cars and crossovers on M12x1.25 studs.

TPMS: Vehicles built before the 2008 model year were not federally required to carry factory TPMS in the US, though many manufacturers adopted it earlier; verify whether your specific build has TPMS before ordering sensor-compatible wheels.

Tire Pressure: Always set tire pressure to the value on your vehicle's tire placard (driver's doorjamb or glovebox), not the max PSI printed on the tire sidewall — this is trim- and tire-size-specific and stays the same reference point when you switch to a different wheel and tire combination.

Reference data compiled from published OEM service specifications and cross-checked against independent repair sources; always confirm against your owner's manual or door-jamb placard before installation.
