2016 Ferrari 488 Spider Wheels & Rims: Bolt Pattern, Offset & Sizes
Fitting Ferrari 488 Spider wheels? This page gives the 2016 Ferrari 488 Spider bolt pattern (5x114.3), centre bore, factory rim size and the offset range for aftermarket and forged Ferrari 488 Spider rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.
Ferrari 488 Spider (2016): 5x114.3 bolt pattern, 67.1mm center bore. Factory wheels: F: 20x9.0J R: 20x11.0J. Reference fitment ranges.
Bolt Pattern5x114.3
Wheel Bolt/NutM14x1.5 Bolt
Center Bore67.1mm
Wheel Load Rating650–750 kg/wheel (Standard Passenger Car segment reference)
Caliper TypeBrembo fixed multi-piston aluminum monoblock caliper (OEM, standard across Ferrari lineup)
Year2016
CategoryConvertible
✓ Data check: the bolt pattern and center bore on this page match an independent fitment reference. Last reviewed September 18, 2026. How we verify
Wheel Size & Offset at a Glance
| Configuration | Wheel Size & Offset |
|---|---|
| Factory (OE) | F: 20x9.0J R: 20x11.0J |
| Flush Fitment | F 20x9.5J ET35 / R 20x11.5J ET32 |
| Maximum Aggressive | F 21x10.0J ET30 / R 21x12.0J ET28 |
Forged Wheel Designs for the Ferrari 488 Spider
Every design below is forged to order, so it can be machined to the Ferrari 488 Spider's 5x114.3 bolt pattern and 67.1 mm center bore, with the width and offset calculated for your setup.
HRE Performance P200-Style Light Gunmetal Cross-Spoke Forged Wheels
Replica · Light Gunmetal
Ferrari OEM-Style Gloss Black 5-Spoke Machined Face Forged Wheels
Monoblock · Gloss Black
Ferrari OEM-Style Gloss Black 5 Twin-Spoke Star Side-Milled Forged Wheels
Replica · Gloss Black
Ferrari OEM-Style Gloss Black 5 Twin-Spoke Star Forged Wheels
Replica · Gloss Black
Matte Silver Cut-Out Forged Wheels
Monoblock · Matte Silver
HRE P200-Style Gloss Black 6 Y-Spoke Forged Wheels
Replica · Gloss Black
HRE Performance P200-Style Bronze Cross-Spoke Forged Wheels
Replica · Bronze
How to Read Wheel Offset & Measurements
Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.
ANKUSI Engineering Expert Advice
With less structural stiffness from the missing roof, a convertible's suspension tuning leans more heavily on unsprung mass control. Forged construction keeps wheel weight down at the same strength rating, which is one less variable working against the Ferrari 488 Spider's chassis.
The Ferrari 488 Spider runs a 5x114.3 bolt pattern, 67.1mm center bore, and a F: 20x9.0J wheel from the factory. Our Flush Fitment reference is F 20x9.5J ET35 / R 20x11.5J ET32, which tucks the tire under the fender lip on a stock-height Ferrari 488 Spider. Our Maximum Aggressive reference is F 21x10.0J ET30 / R 21x12.0J ET28 — beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.
Ferrari 488 Spider OE Wheel Specs
The 2016 Ferrari 488 Spider (Convertible) uses a 5x114.3 bolt pattern with a 67.1mm center bore. Factory wheels are F: 20x9.0J R: 20x11.0J.
Why the factory spec works for most owners:
- Keeps the factory ride quality and noise levels intact
- A common fitment for this class, so replacement tires are easy to source
- Preserves clearance around the OE brakes and suspension geometry
- Delivers predictable, easy-to-live-with handling for daily use
ANKUSI builds these wheels — we are the forging factory, not a reseller. For the Ferrari 488 Spider (2016) we drill the 5x114.3 pattern and cut the centre bore to 67.1mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.
Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.
The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.
Offset & Backspacing Reference
Backspacing is calculated as wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance):
- OE: F 20x9.0J ET42 → ~6.65″ F backspacing, R 20x11.0J ET40 → ~7.57″ R backspacing
- Flush: F 20x9.5J ET35 → ~6.63″ F backspacing, R 20x11.5J ET32 → ~7.51″ R backspacing
- Max: F 21x10.0J ET30 → ~6.68″ F backspacing, R 21x12.0J ET28 → ~7.6″ R backspacing
Want to check a different width or offset before you order? Use our Offset & Backspacing Calculator to solve the numbers yourself, or looking for your exact Ferrari spec, or want a wheel built to a custom offset for your Ferrari 488 Spider? Contact ANKUSI with your bolt pattern and offset target and we will confirm the correct forged wheel spec for your build.
Frequently Asked Questions
What bolt pattern (PCD) does the Ferrari 488 Spider use?
The 2016 Ferrari 488 Spider uses a 5x114.3 bolt pattern.
How many lug bolts does the Ferrari 488 Spider use?
The Ferrari 488 Spider uses a 5-lug bolt pattern (5x114.3), so you need a 5-lug forged wheel to bolt straight on.
What is the center bore size on the Ferrari 488 Spider?
The Ferrari 488 Spider's center bore is 67.1mm. If an aftermarket wheel has a larger center bore than this, hub-centric rings are recommended so the wheel centers on the hub itself rather than relying on the lug bolts alone.
What size are the factory (stock) wheels on the Ferrari 488 Spider?
Factory wheels on the Ferrari 488 Spider are F: 20x9.0J R: 20x11.0J.
What is the biggest wheel size I can fit on my Ferrari 488 Spider without rubbing?
The most aggressive fitment we recommend without fender work is F 21x10.0J ET30 / R 21x12.0J ET28. Going beyond this typically causes rubbing under compression unless you roll the fenders or add camber correction.
What does a flush wheel fitment look like on the Ferrari 488 Spider?
For a flush look with minimal to no rubbing, we recommend F 20x9.5J ET35 / R 20x11.5J ET32 as a starting point on a stock or mildly lowered Ferrari 488 Spider.
Do I need wheel spacers for my Ferrari 488 Spider?
No. ANKUSI forges each wheel to your exact target offset, including the flush or max specs above, so you get the correct fitment without stacking spacers. Spacers are typically only used to push out an existing OE-offset wheel without replacing it, which isn't necessary when you're ordering a custom-offset forged wheel.
How do I calculate wheel backspacing for my Ferrari 488 Spider?
Backspacing (in inches) = wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance). For example, the flush spec above works out to roughly 6.63" backspacing up front and 7.51" in the rear.
What's the difference between wheel offset and backspacing?
Offset is the distance in millimeters from the wheel's true centerline to its mounting face (positive offset pulls the wheel in, negative pushes it out). Backspacing is the distance in inches from the mounting face to the back edge of the wheel barrel. They describe the same fitment from two different reference points, which is why ANKUSI lists both above — some shops and tuning guides quote offset, others quote backspacing.
Can I run staggered wheels (different sizes front and rear) on my Ferrari 488 Spider?
Yes — the Ferrari 488 Spider's factory and our recommended flush/max fitments already use staggered sizing (different width front and rear), and ANKUSI can forge matching staggered sets to your target offsets.
