Forgiato Gunmetal Forged Wheels
Replica · Gunmetal
Fitting Daimler Super Eight wheels? This page gives the 2005 Daimler Super Eight bolt pattern (5x108), centre bore, factory rim size and the offset range for aftermarket and forged Daimler Super Eight rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.
Daimler Super Eight (2005): 5x108 bolt pattern, 63.4mm center bore. Factory wheels: 18x8.0J F/R. Reference fitment ranges.
Data check: the bolt pattern and center bore on this page have not yet been confirmed by a second independent source. Measure your hub or ask us before ordering. How we verify
| Configuration | Wheel Size & Offset |
|---|---|
| Factory (OE) | 18x8.0J F/R |
| Flush Fitment | 20x9.0J at ET35 offset |
| Maximum Aggressive | 21x9.5J at ET35 offset |
Every design below is forged to order, so it can be machined to the Daimler Super Eight's 5x108 bolt pattern and 63.4 mm center bore, with the width and offset calculated for your setup.

Replica · Gunmetal

Monoblock · Carbon

Monoblock · Gloss White

Monoblock · Gloss Black

Monoblock · Gloss Black

Monoblock · Black Machined

Replica · Silver

Monoblock · Satin Black
Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.


The Daimler Super Eight's factory wheel spec reflects a deliberate balance between comfort, steering feel and durability that the engineering team tuned for. Forging lets ANKUSI match that same strength target while trimming rotational mass — the part of a wheel upgrade that actually changes how the car drives, not just how it looks.
The Daimler Super Eight runs a 5x108 bolt pattern, 63.4mm center bore, and a 18x8.0J, front and rear, wheel from the factory. Our Flush Fitment reference is 20x9.0J ET35, which tucks the tire under the fender lip on a stock-height Daimler Super Eight. Our Maximum Aggressive reference is 21x9.5J ET35 — beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.
The 2005 Daimler Super Eight (Luxury Sedan) uses a 5x108 bolt pattern with a 63.4mm center bore. Factory wheels are 18x8.0J F/R.
Why the factory spec works for most owners:
ANKUSI builds these wheels — we are the forging factory, not a reseller. For the Daimler Super Eight (2005) we drill the 5x108 pattern and cut the centre bore to 63.4mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.
Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.
The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.
Backspacing is calculated as wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance):
Want to check a different width or offset before you order? Use our Offset & Backspacing Calculator to solve the numbers yourself, or looking for your exact Daimler spec, or want a wheel built to a custom offset for your Daimler Super Eight? Contact ANKUSI with your bolt pattern and offset target and we will confirm the correct forged wheel spec for your build.
