Corvette OEM-Style Gloss Black 5 Split-Spoke Forged Wheels
Monoblock · Gloss Black
1969 Chevrolet Chevelle Wheels & Rims: Bolt Pattern, Offset & Sizes
Fitting Chevrolet Chevelle wheels? This page gives the 1969 Chevrolet Chevelle bolt pattern (5x120.65), centre bore, factory rim size and the offset range for aftermarket and forged Chevrolet Chevelle rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.
Forged wheels for Chevrolet — styles, sizes & factory quote →
Chevrolet Chevelle (1969): 5x120.65 bolt pattern, 70.3mm center bore. Factory wheels: 14x6.0J F/R. Reference fitment ranges.
Bolt Pattern5x120.65
Wheel Bolt/NutM12x1.5 Nut
Center Bore70.3mm
Wheel Load Rating650–750 kg/wheel (Standard Passenger Car segment reference)
Year1969
CategoryCoupe/Sedan
Data check: the bolt pattern and center bore on this page have not yet been confirmed by a second independent source. Measure your hub or ask us before ordering. How we verify
Wheel Size & Offset at a Glance
| Configuration | Wheel Size & Offset |
|---|---|
| Factory (OE) | 14x6.0J F/R |
| Flush Fitment | 17x8.5J at ET-10 offset |
| Maximum Aggressive | 18x10.0J at ET-15 offset |
Forged Wheel Designs for the Chevrolet Chevelle
Every design below is forged to order, so it can be machined to the Chevrolet Chevelle's 5x120.65 bolt pattern and 70.3 mm center bore, with the width and offset calculated for your setup.
Gloss White 6-Spoke Forged Wheels
Monoblock · Gloss White
Weld Racing-Style Gloss Black Polished Lip Forged Drag Racing Wheels
Drag Racing · Gloss Black / Polished
Chevrolet OEM-Style Gloss Black 5-Spoke Machined Face Forged Wheels
Monoblock · Gloss Black
Belak Custom Finish 5-Star Spoke Racing Forged Drag Racing Wheels
Drag Racing · Custom Finish
Polished Silver 5 V-Spoke Forged Wheels
Monoblock · Polished Silver
JXDL-Style Brushed Silver 5 Y-Spoke Concave Forged Wheels
Concave · Brushed Silver
Mirror Polished Swirl Smoothie Forged Wheels
Monoblock · Chrome
How to Read Wheel Offset & Measurements
Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.
ANKUSI Engineering Expert Advice
On a performance-oriented coupe, the wheel is one of the few components where shaving weight has a compounding effect — less rotational mass means less work for the brakes, the drivetrain, and the chassis on every input. A forged wheel gets there without compromising the strength margin the factory engineered in.
The Chevrolet Chevelle runs a 5x120.65 bolt pattern, 70.3mm center bore, and a 14x6.0J, front and rear, wheel from the factory. Our Flush Fitment reference is 17x8.5J ET-10, which tucks the tire under the fender lip on a stock-height Chevrolet Chevelle. Our Maximum Aggressive reference is 18x10.0J ET-15 — beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.
Chevrolet Chevelle OE Wheel Specs
The 1969 Chevrolet Chevelle (Coupe/Sedan) uses a 5x120.65 bolt pattern with a 70.3mm center bore. Factory wheels are 14x6.0J F/R.
Why the factory spec works for most owners:
- Keeps the factory ride quality and noise levels intact
- A common fitment for this class, so replacement tires are easy to source
- Preserves clearance around the OE brakes and suspension geometry
- Delivers predictable, easy-to-live-with handling for daily use
ANKUSI builds these wheels — we are the forging factory, not a reseller. For the Chevrolet Chevelle (1969) we drill the 5x120.65 pattern and cut the centre bore to 70.3mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.
Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.
The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.
Offset & Backspacing Reference
Backspacing is calculated as wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance):
- OE: 14x6.0J ET0 → ~3.5″ backspacing
- Flush: 17x8.5J ET-10 → ~4.36″ backspacing
- Max: 18x10.0J ET-15 → ~4.91″ backspacing
Want to check a different width or offset before you order? Use our Offset & Backspacing Calculator to solve the numbers yourself, or looking for your exact Chevrolet spec, or want a wheel built to a custom offset for your Chevrolet Chevelle? Contact ANKUSI with your bolt pattern and offset target and we will confirm the correct forged wheel spec for your build.
Frequently Asked Questions
What bolt pattern (PCD) does the Chevrolet Chevelle use?
The 1969 Chevrolet Chevelle uses a 5x120.65 bolt pattern.
How many lug bolts does the Chevrolet Chevelle use?
The Chevrolet Chevelle uses a 5-lug bolt pattern (5x120.65), so you need a 5-lug forged wheel to bolt straight on.
What is the center bore size on the Chevrolet Chevelle?
The Chevrolet Chevelle's center bore is 70.3mm. If an aftermarket wheel has a larger center bore than this, hub-centric rings are recommended so the wheel centers on the hub itself rather than relying on the lug bolts alone.
What size are the factory (stock) wheels on the Chevrolet Chevelle?
Factory wheels on the Chevrolet Chevelle are 14x6.0J F/R.
What is the biggest wheel size I can fit on my Chevrolet Chevelle without rubbing?
The most aggressive fitment we recommend without fender work is 18x10.0J at ET-15 offset. Going beyond this typically causes rubbing under compression unless you roll the fenders or add camber correction.
What does a flush wheel fitment look like on the Chevrolet Chevelle?
For a flush look with minimal to no rubbing, we recommend 17x8.5J at ET-10 offset as a starting point on a stock or mildly lowered Chevrolet Chevelle.
Do I need wheel spacers for my Chevrolet Chevelle?
No. ANKUSI forges each wheel to your exact target offset, including the flush or max specs above, so you get the correct fitment without stacking spacers. Spacers are typically only used to push out an existing OE-offset wheel without replacing it, which isn't necessary when you're ordering a custom-offset forged wheel.
How do I calculate wheel backspacing for my Chevrolet Chevelle?
Backspacing (in inches) = wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance). For example, the flush spec above works out to roughly 4.36" of backspacing.
What's the difference between wheel offset and backspacing?
Offset is the distance in millimeters from the wheel's true centerline to its mounting face (positive offset pulls the wheel in, negative pushes it out). Backspacing is the distance in inches from the mounting face to the back edge of the wheel barrel. They describe the same fitment from two different reference points, which is why ANKUSI lists both above — some shops and tuning guides quote offset, others quote backspacing.
Can I run staggered wheels (different sizes front and rear) on my Chevrolet Chevelle?
The Chevrolet Chevelle runs the same wheel size front and rear from the factory, so staggered fitment is not required. ANKUSI can still forge a staggered set (wider rear) on request if you want a more aggressive stance.
Wheel Installation Reference: Torque, Thread & TPMS
Thread & Fastener: M12x1.5, conical-seat lug nut.
Factory Torque Spec: 136 Nm (100 ft-lb). Covers most Chevrolet passenger cars and crossovers on M12 studs.
TPMS: Vehicles built before the 2008 model year were not federally required to carry factory TPMS in the US, though many manufacturers adopted it earlier; verify whether your specific build has TPMS before ordering sensor-compatible wheels.
Tire Pressure: Always set tire pressure to the value on your vehicle's tire placard (driver's doorjamb or glovebox), not the max PSI printed on the tire sidewall — this is trim- and tire-size-specific and stays the same reference point when you switch to a different wheel and tire combination.
Reference data compiled from published OEM service specifications and cross-checked against independent repair sources; always confirm against your owner's manual or door-jamb placard before installation.
