2009 Breckland Beira Wheels & Rims: Bolt Pattern, Offset & Sizes

Fitting Breckland Beira wheels? This page gives the 2009 Breckland Beira bolt pattern (5x110), centre bore, factory rim size and the offset range for aftermarket and forged Breckland Beira rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.

Breckland Beira (2009): 5x110 bolt pattern, 65.1mm center bore. Factory wheels: 19x8.5J F/R. Reference fitment ranges.

Bolt Pattern5x110
Center Bore65.1mm
Wheel Load Rating650–750 kg/wheel (Standard Passenger Car segment reference)
Year2009
CategoryRoadster

Data check: the bolt pattern and center bore on this page have not yet been confirmed by a second independent source. Measure your hub or ask us before ordering. How we verify

Use this spec on your site

Paste this code into a forum post, listing or web page to show the Breckland Beira 2009 bolt pattern, center bore and factory wheel size. Free, no sign-up.

<iframe src="https://ankusiwheels.com/wp-content/uploads/ankusi-embed/lookup.html?vehicle=breckland-beira-2009&card=1" width="100%" height="230" style="border:0;max-width:560px" loading="lazy" title="Breckland Beira 2009 bolt pattern"></iframe>
<p style="font-size:13px"><a href="https://ankusiwheels.com/fitment-guide/breckland-beira-2009/">Breckland Beira 2009 bolt pattern and offset guide</a> by ANKUSI Wheels</p>

More free tools: bolt pattern lookup and offset calculator for your website.

Wheel Size & Offset at a Glance

Breckland Beira wheel size and offset comparison by configuration
ConfigurationWheel Size & Offset
Factory (OE)19x8.5J F/R
Flush Fitment19x9.0J at ET40 offset
Maximum Aggressive19x9.5J at ET35 offset

Forged Wheel Designs for the Breckland Beira

Every design below is forged to order, so it can be machined to the Breckland Beira's 5x110 bolt pattern and 65.1 mm center bore, with the width and offset calculated for your setup.

How to Read Wheel Offset & Measurements

Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.

Diagram showing wheel measurement points: centerline, center bore diameter, PCD, offset, rim width and diameter
Centerline, center bore, PCD, offset, width & diameter
Diagram comparing positive, zero, and negative wheel offset relative to the wheel centerline
Positive vs. zero vs. negative offset

ANKUSI Engineering Expert Advice

Convertibles lose some of the structural rigidity a fixed roof provides, which means the suspension and wheels end up doing more of the work to keep the chassis composed. A forged wheel keeps unsprung mass down without sacrificing the strength margin the factory built in — useful on a platform that's already managing extra flex.

The Breckland Beira runs a 5x110 bolt pattern, 65.1mm center bore, and a 19x8.5J, front and rear, wheel from the factory. Our Flush Fitment reference is 19x9.0J ET40, which tucks the tire under the fender lip on a stock-height Breckland Beira. Our Maximum Aggressive reference is 19x9.5J ET35 — beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.

Breckland Beira OE Wheel Specs

The 2009 Breckland Beira (Roadster) uses a 5x110 bolt pattern with a 65.1mm center bore. Factory wheels are 19x8.5J F/R.

Why the factory spec works for most owners:

  • Preserves the factory-tuned ride and steering feel
  • A mainstream size for this segment, keeping tire choice wide and prices reasonable
  • Leaves full clearance for the stock brakes and suspension hardware
  • Keeps handling predictable and consistent in everyday conditions

ANKUSI builds these wheels — we are the forging factory, not a reseller. For the Breckland Beira (2009) we drill the 5x110 pattern and cut the centre bore to 65.1mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.

IATF 16949 & ISO 9001 certified · own 10,000-ton press in Guangzhou · from a single set to a full container

Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.

The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.

Offset & Backspacing Reference

Backspacing is calculated as wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance):

  • OE: 19x8.5J ET55 → ~6.92″ backspacing
  • Flush: 19x9.0J ET40 → ~6.57″ backspacing
  • Max: 19x9.5J ET35 → ~6.63″ backspacing

Want to check a different width or offset before you order? Use our Offset & Backspacing Calculator to solve the numbers yourself, or looking for your exact Breckland spec, or want a wheel built to a custom offset for your Breckland Beira? Contact ANKUSI with your bolt pattern and offset target and we will confirm the correct forged wheel spec for your build.

Frequently Asked Questions

What bolt pattern (PCD) does the Breckland Beira use?
The 2009 Breckland Beira uses a 5x110 bolt pattern.
How many lug bolts does the Breckland Beira use?
The Breckland Beira uses a 5-lug bolt pattern (5x110), so you need a 5-lug forged wheel to bolt straight on.
What is the center bore size on the Breckland Beira?
The Breckland Beira's center bore is 65.1mm. If an aftermarket wheel has a larger center bore than this, hub-centric rings are recommended so the wheel centers on the hub itself rather than relying on the lug bolts alone.
What size are the factory (stock) wheels on the Breckland Beira?
Factory wheels on the Breckland Beira are 19x8.5J F/R.
What is the biggest wheel size I can fit on my Breckland Beira without rubbing?
The most aggressive fitment we recommend without fender work is 19x9.5J at ET35 offset. Going beyond this typically causes rubbing under compression unless you roll the fenders or add camber correction.
What does a flush wheel fitment look like on the Breckland Beira?
For a flush look with minimal to no rubbing, we recommend 19x9.0J at ET40 offset as a starting point on a stock or mildly lowered Breckland Beira.
Do I need wheel spacers for my Breckland Beira?
No. ANKUSI forges each wheel to your exact target offset, including the flush or max specs above, so you get the correct fitment without stacking spacers. Spacers are typically only used to push out an existing OE-offset wheel without replacing it, which isn't necessary when you're ordering a custom-offset forged wheel.
How do I calculate wheel backspacing for my Breckland Beira?
Backspacing (in inches) = wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance). For example, the flush spec above works out to roughly 6.57" of backspacing.
What's the difference between wheel offset and backspacing?
Offset is the distance in millimeters from the wheel's true centerline to its mounting face (positive offset pulls the wheel in, negative pushes it out). Backspacing is the distance in inches from the mounting face to the back edge of the wheel barrel. They describe the same fitment from two different reference points, which is why ANKUSI lists both above — some shops and tuning guides quote offset, others quote backspacing.
Can I run staggered wheels (different sizes front and rear) on my Breckland Beira?
The Breckland Beira runs the same wheel size front and rear from the factory, so staggered fitment is not required. ANKUSI can still forge a staggered set (wider rear) on request if you want a more aggressive stance.
