2008 ABT Audi R8 Wheels & Rims: Bolt Pattern, Offset & Sizes

Fitting ABT Audi R8 wheels? This page gives the 2008 ABT Audi R8 bolt pattern (5x112), centre bore, factory rim size and the offset range for aftermarket and forged ABT Audi R8 rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.

ABT Audi R8 (2008): 5x112 bolt pattern, 57.1mm center bore. Factory wheels: F: 20x9.0J R: 20x11.0J. Reference fitment ranges.

Bolt Pattern5x112
Wheel Bolt/NutM14x1.5 Bolt
Center Bore57.1mm
Wheel Load Rating700–850 kg/wheel (Performance / Sports Car segment reference)
Year2008
CategorySupercar

✓ Data check: the bolt pattern and center bore on this page match an independent fitment reference. Last reviewed September 18, 2026. How we verify

Use this spec on your site

Paste this code into a forum post, listing or web page to show the ABT Audi R8 2008 bolt pattern, center bore and factory wheel size. Free, no sign-up.

<iframe src="https://ankusiwheels.com/wp-content/uploads/ankusi-embed/lookup.html?vehicle=abt-audi-r8-2008&card=1" width="100%" height="230" style="border:0;max-width:560px" loading="lazy" title="ABT Audi R8 2008 bolt pattern"></iframe>
<p style="font-size:13px"><a href="https://ankusiwheels.com/fitment-guide/abt-audi-r8-2008/">ABT Audi R8 2008 bolt pattern and offset guide</a> by ANKUSI Wheels</p>

More free tools: bolt pattern lookup and offset calculator for your website.

Wheel Size & Offset at a Glance

ABT Audi R8 wheel size and offset comparison by configuration
ConfigurationWheel Size & Offset
Factory (OE)F: 20x9.0J R: 20x11.0J
Flush FitmentF 20x9.0J ET35 / R 20x11.5J ET40
Maximum AggressiveF 21x9.5J ET30 / R 21x12.0J ET35

Forged Wheel Designs for the ABT Audi R8

Every design below is forged to order, so it can be machined to the ABT Audi R8's 5x112 bolt pattern and 57.1 mm center bore, with the width and offset calculated for your setup.

How to Read Wheel Offset & Measurements

Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.

Diagram showing wheel measurement points: centerline, center bore diameter, PCD, offset, rim width and diameter
Centerline, center bore, PCD, offset, width & diameter
Diagram comparing positive, zero, and negative wheel offset relative to the wheel centerline
Positive vs. zero vs. negative offset

ANKUSI Engineering Expert Advice

On a supercar, wheel weight is one of the few remaining places to cut rotational mass without touching the powertrain or chassis the factory already optimized. Forging gets there at the same structural margin as the OE wheel, which is exactly the trade a car built around outright performance rewards.

The ABT Audi R8 runs a 5x112 bolt pattern, 57.1mm center bore, and a F: 20x9.0J wheel from the factory. Our Flush Fitment reference is F 20x9.0J ET35 / R 20x11.5J ET40, which tucks the tire under the fender lip on a stock-height ABT Audi R8. Our Maximum Aggressive reference is F 21x9.5J ET30 / R 21x12.0J ET35 — beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.

ABT Audi R8 OE Wheel Specs

The 2008 ABT Audi R8 (Supercar) uses a 5x112 bolt pattern with a 57.1mm center bore. Factory wheels are F: 20x9.0J R: 20x11.0J.

Why the factory spec works for most owners:

  • Balances ride comfort with everyday fuel efficiency
  • A widely used size in this segment, so tire and wheel availability stays strong
  • Keeps unsprung weight low for stable, predictable handling
  • Maintains clearance for the factory brake calipers and suspension components

ANKUSI builds these wheels — we are the forging factory, not a reseller. For the ABT Audi R8 (2008) we drill the 5x112 pattern and cut the centre bore to 57.1mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.

IATF 16949 & ISO 9001 certified · own 10,000-ton press in Guangzhou · from a single set to a full container

Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.

The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.

Offset & Backspacing Reference

Backspacing is calculated as wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance):

  • OE: F 20x9.0J ET42 → ~6.65″ F backspacing, R 20x11.0J ET50 → ~7.97″ R backspacing
  • Flush: F 20x9.0J ET35 → ~6.38″ F backspacing, R 20x11.5J ET40 → ~7.82″ R backspacing
  • Max: F 21x9.5J ET30 → ~6.43″ F backspacing, R 21x12.0J ET35 → ~7.88″ R backspacing

Want to check a different width or offset before you order? Use our Offset & Backspacing Calculator to solve the numbers yourself, or looking for your exact abt spec, or want a wheel built to a custom offset for your ABT Audi R8? Contact ANKUSI with your bolt pattern and offset target and we will confirm the correct forged wheel spec for your build.

Frequently Asked Questions

What bolt pattern (PCD) does the ABT Audi R8 use?
The 2008 ABT Audi R8 uses a 5x112 bolt pattern.
How many lug bolts does the ABT Audi R8 use?
The ABT Audi R8 uses a 5-lug bolt pattern (5x112), so you need a 5-lug forged wheel to bolt straight on.
What is the center bore size on the ABT Audi R8?
The ABT Audi R8's center bore is 57.1mm. If an aftermarket wheel has a larger center bore than this, hub-centric rings are recommended so the wheel centers on the hub itself rather than relying on the lug bolts alone.
What size are the factory (stock) wheels on the ABT Audi R8?
Factory wheels on the ABT Audi R8 are F: 20x9.0J R: 20x11.0J.
What is the biggest wheel size I can fit on my ABT Audi R8 without rubbing?
The most aggressive fitment we recommend without fender work is F 21x9.5J ET30 / R 21x12.0J ET35. Going beyond this typically causes rubbing under compression unless you roll the fenders or add camber correction.
What does a flush wheel fitment look like on the ABT Audi R8?
For a flush look with minimal to no rubbing, we recommend F 20x9.0J ET35 / R 20x11.5J ET40 as a starting point on a stock or mildly lowered ABT Audi R8.
Do I need wheel spacers for my ABT Audi R8?
No. ANKUSI forges each wheel to your exact target offset, including the flush or max specs above, so you get the correct fitment without stacking spacers. Spacers are typically only used to push out an existing OE-offset wheel without replacing it, which isn't necessary when you're ordering a custom-offset forged wheel.
How do I calculate wheel backspacing for my ABT Audi R8?
Backspacing (in inches) = wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance). For example, the flush spec above works out to roughly 6.38" backspacing up front and 7.82" in the rear.
What's the difference between wheel offset and backspacing?
Offset is the distance in millimeters from the wheel's true centerline to its mounting face (positive offset pulls the wheel in, negative pushes it out). Backspacing is the distance in inches from the mounting face to the back edge of the wheel barrel. They describe the same fitment from two different reference points, which is why ANKUSI lists both above — some shops and tuning guides quote offset, others quote backspacing.
Can I run staggered wheels (different sizes front and rear) on my ABT Audi R8?
Yes — the ABT Audi R8's factory and our recommended flush/max fitments already use staggered sizing (different width front and rear), and ANKUSI can forge matching staggered sets to your target offsets.
