Chevrolet Tahoe Bolt Pattern, Center Bore & Wheel Offset (2000–2025)
Chevrolet Tahoe wheel fitment: 6x139.7 bolt pattern, 78.1mm center bore (2000–2025).
- 6x139.7bolt pattern (PCD)
- 78.1 mmcenter bore
- M12x1.5 Nutwheel bolt / nut
- 8 guidesmodel years 2000–2025
Chevrolet Tahoe wheel specs by year and trim
| Year | Model / trim | Bolt pattern | Center bore | OE wheel |
|---|---|---|---|---|
| 2025 | Chevrolet Tahoe | 6x139.7 | 78.1 mm | 22x9.0J ET24 |
| 2021 | Chevrolet Tahoe | 6x139.7 | 78.1 mm | 22x9.0J |
| 2018 | Chevrolet Tahoe RST | 6x139.7 | 78.1 mm | 22x9.0J |
| 2015 | Chevrolet Tahoe | 6x139.7 | 78.1 mm | 20x9.0J |
| 2015 | Chevrolet Tahoe Z71 | 6x139.7 | 78.1 mm | 18x8.5J |
| 2007 | Chevrolet Tahoe | 6x139.7 | 78.1 mm | 17x7.5J |
| 2002 | Chevrolet Tahoe | 6x139.7 | 78.1 mm | 16x7.0J |
| 2000 | Chevrolet Tahoe | 6x139.7 | 78.1 mm | 16x7.0J |
Factory wheel sizes on the Chevrolet Tahoe
Across the 8 Chevrolet Tahoe trims with a documented factory wheel, the OE diameter is 16-22 inch, width 7-9J and offset ET24. A forged wheel that keeps the 6x139.7 bolt pattern and the 78.1 mm hub bore and stays inside that offset range bolts on without spacers or hub rings. Going one inch up in diameter with a lower-profile tyre keeps the rolling circumference inside the usual 1.5% tolerance; every extra 0.5J of width moves the outer lip about 6 mm outward at the same offset, and each 5 mm less offset moves the whole wheel 5 mm outward.
Forged wheels for the Chevrolet Tahoe (6x139.7)
Shop all Chevrolet Tahoe forged wheels →
Get a quote for Chevrolet Tahoe wheels
Vehicles With the Same Hub as the Chevrolet Tahoe (6x139.7, 78.1 mm Bore)
In our database, 48 other vehicle entries from 5 makes use exactly the same 6x139.7 bolt pattern and 78.1 mm center bore. Factory wheels from these cars bolt on and center on the hub without rings; offset and width still have to be checked.
6x139.7 is used by 4.0% of the vehicle pages in our English fitment guide (258 of 6,503); 31.0% of those also use a 78.1 mm center bore.
Offset and Backspacing: Factory Wheel vs Options
Backspacing ≈ width/2 + ET/25.4 + 0.5 in. "Inward" means closer to the suspension; "outward" means closer to the fender lip.
| Setup | Size | ET | Backspacing | Inward vs OE | Outward vs OE |
|---|---|---|---|---|---|
| Factory (OE) | 22x9J | ET24 | 5.94 in (151 mm) | — | — |
| Maximum | 26x10.5J | ET10 | 6.14 in (156 mm) | +5 mm | +33 mm |
Hub-Centric Rings for a 78.1 mm Center Bore
A wheel with a center bore larger than 78.1 mm needs a hub-centric ring. The most common combinations:
| Wheel bore | Ring size |
|---|---|
| 84.1 mm | 84.1 → 78.1 mm |
| 93.1 mm | 93.1 → 78.1 mm |
| 100.1 mm | 100.1 → 78.1 mm |
| 106.1 mm | 106.1 → 78.1 mm |
ANKUSI forged wheels are bored to exactly 78.1 mm for this vehicle, so no ring is needed.
Sources and Last Update
Bolt pattern and center bore were checked against at least two independent fitment references before publication.
This record is part of the open ANKUSI Wheel Fitment Dataset (DOI 10.5281/zenodo.23241521, CC BY 4.0).
Compiled by the ANKUSI Wheels engineering team, an IATF 16949 and ISO 9001 certified forged wheel factory in Guangzhou.
FAQ
What is the bolt pattern on a Chevrolet Tahoe?
The Chevrolet Tahoe uses a 6x139.7 bolt pattern with a 78.1mm center bore across every Tahoe variant in our database (8 guides, 2000–2025).
What is the Chevrolet Tahoe center bore?
The hub-centric center bore is 78.1 mm. Aftermarket wheels should match this bore or use hub-centric rings so the hub, not the bolts, carries the load.
Do all Chevrolet Tahoe years share the same wheel fitment?
The bolt pattern and center bore are the same across the years we cover, but OE wheel width and offset differ by trim, so check the exact model line before choosing an aftermarket size.
Which forged wheels fit the Chevrolet Tahoe?
Any wheel drilled 6x139.7 with a 78.1mm hub bore in the offset range shown on the model guide. ANKUSI forges wheels to order for this exact specification, in 14–24 inch diameters, so no adapters or hub rings are needed.
