2019 Ford Fusion Wheels & Rims: Bolt Pattern, Offset & Sizes
Fitting Ford Fusion wheels? This page gives the 2019 Ford Fusion bolt pattern (5x108), centre bore, factory rim size and the offset range for aftermarket and forged Ford Fusion rims: the same spec sheet ANKUSI uses when machining forged wheels for this car.
Quick answer: The 2019 Ford Fusion uses a 5x108 bolt pattern with a 63.4 mm centre bore and M12x1.5 lug nuts. Factory wheels: 17x7.5J, front and rear. For aftermarket wheels, 18x8.5J ET38 sits flush and 19x9.0J ET35 is the most aggressive fit.
Forged wheels for the 2019 Ford Fusion — drilled 5x108 with a 63.4 mm centre bore, built to the offset you choose. From $220 per wheel, made to order in 20–25 days.
Get a quote for this car
Ford Fusion (2019): 5x108 bolt pattern, 63.4mm center bore. Factory wheels: 17x7.5J F/R. Reference fitment ranges.
Bolt Pattern5x108
Wheel Bolt/NutM12x1.5 Nut
Center Bore63.4mm
Wheel Load Rating650–750 kg/wheel (Standard Passenger Car segment reference)
Year2019
CategorySedan
✓ Data check: the bolt pattern and center bore on this page match an independent fitment reference. Last reviewed September 25, 2026. How we verify
Wheel Size & Offset at a Glance
| Configuration | Wheel Size & Offset |
|---|---|
| Factory (OE) | 17x7.5J F/R |
| Flush Fitment | 18x8.5J at ET38 offset |
| Maximum Aggressive | 19x9.0J at ET35 offset |
Forged Wheel Designs for the Ford Fusion
Every design below is forged to order, so it can be machined to the Ford Fusion's 5x108 bolt pattern and 63.4 mm center bore, with the width and offset calculated for your setup.
Ford ST OEM-Style Gloss Black 10 Y-Spoke Forged Wheels
Monoblock · Gloss Black
Ford Mustang OEM-Style Hyper Silver 5 Y-Spoke Concave Forged Wheels
Concave · Hyper Silver
Ford Mustang OEM-Style Gunmetal Swirl Turbine Forged Wheels
Monoblock · Gunmetal
ECC Bronze 5 Y-Spoke Beadlock Forged Wheels
Off-Road Beadlock · Bronze
Weld Racing-Style Gloss Black Milled 14-Spoke Mesh Beadlock Forged Drag Racing Wheels
Drag Racing · Custom Finish
Weld Racing S71-Style Gloss Black / Polished Beadlock Forged Drag Racing Wheels
Drag Racing · Gloss Black / Polished
Side-Milled Transparent Gray 5 Y-Spoke Forged Wheels
Monoblock · Side-milled Transparent Gray
How to Read Wheel Offset & Measurements
Use these two references before ordering: the left diagram shows where each spec (PCD, center bore, offset, width and diameter) is measured on the wheel; the right diagram shows how positive, zero and negative offset shift the wheel face relative to the hub centerline.
ANKUSI Engineering Expert Advice
Most of the engineering value in a forged wheel over a cast one shows up in rotational mass, not outright strength — both can meet the same load rating, but the forged piece gets there lighter. On a sedan platform tuned for everyday balance, that weight saving is felt directly in steering response and ride quality.
The Ford Fusion runs a 5*108 bolt pattern, 63.4mm center bore, and a 17x7.5J, front and rear, wheel from the factory. Our Flush Fitment reference is 18x8.5J ET38, which tucks the tire under the fender lip on a stock-height Ford Fusion. Our Maximum Aggressive reference is 19x9.0J ET35 — beyond that offset, expect rubbing against the inner fender liner under compression without further trimming.
Ford Fusion OE Wheel Specs
The 2019 Ford Fusion (Sedan) uses a 5*108 bolt pattern with a 63.4mm center bore. Factory wheels are 17x7.5J F/R.
Why the factory spec works for most owners:
- Balances ride comfort with everyday fuel efficiency
- A widely used size in this segment, so tire and wheel availability stays strong
- Keeps unsprung weight low for stable, predictable handling
- Maintains clearance for the factory brake calipers and suspension components
ANKUSI builds these wheels — we are the forging factory, not a reseller. For the Ford Fusion (2019) we drill the 5x108 pattern and cut the centre bore to 63.4mm on our own CNC line, so the wheel hub-centres on the car with no spacer rings, in whatever diameter, width and offset you specify.
Converting these ET figures to backspacing? Use the wheel offset and backspacing calculator.
The figures on this page are part of our open wheel fitment dataset — 10,093 vehicles, free to download, CC BY 4.0.
Offset & Backspacing Reference
Backspacing is calculated as wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance):
- Flush: 18x8.5J ET38 → ~6.25″ backspacing
- Max: 19x9J ET35 → ~6.38″ backspacing
Want to check a different width or offset before you order? Use our Offset & Backspacing Calculator to solve the numbers yourself, or looking for your exact Ford spec, or want a wheel built to a custom offset for your Ford Fusion? Contact ANKUSI with your bolt pattern and offset target and we will confirm the correct forged wheel spec for your build.
Vehicles With the Same Hub as the Ford Fusion (5x108, 63.4 mm Bore)
In our database, 278 other vehicle entries from 17 makes use exactly the same 5x108 bolt pattern and 63.4 mm center bore. Factory wheels from these cars bolt on and center on the hub without rings; offset and width still have to be checked.
5x108 is used by 7.7% of the vehicle pages in our English fitment guide (499 of 6,503); 55.9% of those also use a 63.4 mm center bore.
Hub-Centric Rings for a 63.4 mm Center Bore
A wheel with a center bore larger than 63.4 mm needs a hub-centric ring. The most common combinations:
| Wheel bore | Ring size |
|---|---|
| 64.1 mm | 64.1 → 63.4 mm |
| 65.1 mm | 65.1 → 63.4 mm |
| 66.1 mm | 66.1 → 63.4 mm |
| 66.6 mm | 66.6 → 63.4 mm |
| 73.1 mm | 73.1 → 63.4 mm |
ANKUSI forged wheels are bored to exactly 63.4 mm for this vehicle, so no ring is needed.
Frequently Asked Questions
What bolt pattern (PCD) does the Ford Fusion use?
The 2019 Ford Fusion uses a 5x108 bolt pattern.
How many lug bolts does the Ford Fusion use?
The Ford Fusion uses a 5-lug bolt pattern (5x108), so you need a 5-lug forged wheel to bolt straight on.
What is the center bore size on the Ford Fusion?
The Ford Fusion's center bore is 63.4mm. If an aftermarket wheel has a larger center bore than this, hub-centric rings are recommended so the wheel centers on the hub itself rather than relying on the lug bolts alone.
What size are the factory (stock) wheels on the Ford Fusion?
Factory wheels on the Ford Fusion are 17x7.5J F/R.
What is the biggest wheel size I can fit on my Ford Fusion without rubbing?
The most aggressive fitment we recommend without fender work is 19x9.0J at ET35 offset. Going beyond this typically causes rubbing under compression unless you roll the fenders or add camber correction.
What does a flush wheel fitment look like on the Ford Fusion?
For a flush look with minimal to no rubbing, we recommend 18x8.5J at ET38 offset as a starting point on a stock or mildly lowered Ford Fusion.
Do I need wheel spacers for my Ford Fusion?
No. ANKUSI forges each wheel to your exact target offset, including the flush or max specs above, so you get the correct fitment without stacking spacers. Spacers are typically only used to push out an existing OE-offset wheel without replacing it, which isn't necessary when you're ordering a custom-offset forged wheel.
How do I calculate wheel backspacing for my Ford Fusion?
Backspacing (in inches) = wheel width (in) ÷ 2 + offset (mm) ÷ 25.4 + 0.5 (flange allowance). For example, the flush spec above works out to roughly 6.25" of backspacing.
What's the difference between wheel offset and backspacing?
Offset is the distance in millimeters from the wheel's true centerline to its mounting face (positive offset pulls the wheel in, negative pushes it out). Backspacing is the distance in inches from the mounting face to the back edge of the wheel barrel. They describe the same fitment from two different reference points, which is why ANKUSI lists both above — some shops and tuning guides quote offset, others quote backspacing.
Can I run staggered wheels (different sizes front and rear) on my Ford Fusion?
The Ford Fusion runs the same wheel size front and rear from the factory, so staggered fitment is not required. ANKUSI can still forge a staggered set (wider rear) on request if you want a more aggressive stance.
Wheel Installation Reference: Torque, Thread & TPMS
Thread & Fastener: M12x1.5, conical-seat lug nut.
Factory Torque Spec: 136 Nm (100 ft-lb). Covers most Ford passenger cars and crossovers (Fusion, Focus, Escape and similar) on M12x1.5 studs.
TPMS: TPMS (Tire Pressure Monitoring System) has been federally mandated on all new light vehicles sold in the US since the 2008 model year. If your wheels use OE-style sensors, have them transferred or cloned to the new wheels at installation.
Tire Pressure: Always set tire pressure to the value on your vehicle's tire placard (driver's doorjamb or glovebox), not the max PSI printed on the tire sidewall — this is trim- and tire-size-specific and stays the same reference point when you switch to a different wheel and tire combination.
Reference data compiled from published OEM service specifications and cross-checked against independent repair sources; always confirm against your owner's manual or door-jamb placard before installation.
Sources and Last Update
Data checked against: avtoreference.com.
This record is part of the open ANKUSI Wheel Fitment Dataset (DOI 10.5281/zenodo.23241521, CC BY 4.0).
